5 Appendix: FIXED AntennaS
The table below identifies the distances where the 1mW/cm
2
exposure limits may
be exceeded during continuous transmission using the proposed fixed antennas.
MDR5800
Manufacturer Type Model Gain
(dBi)
Numeric
gain
Peak
Power
(mW)
Calculated
Distance (m)
Minimum RF
Exposure
Separation
Distance (m)
Gabriel Dish SSP2 52B 29.0 794.3 239.9 1.2 2
Gabriel Flat panel DFPD1-52 23.9 245.5 239.9 0.7 2
MTI Flat panel MT-20004 28.0 631.0 239.9 1.1 2
ORION5850
Manufacturer Type Model Gain
(dBi)
Numeric
gain
Peak
Power
(mW)
Calculated
Distance (m)
Minimum RF
Exposure
Separation
Distance (m)
Gabriel Dish SSP2 52B 29.0 794.3 239.9 1.2 2
MTI Flat panel MT-20004 28.0 631.0 239.9 1.1 2
MDR2400
Manufacturer Type Model Gain
(dBi)
Numeric
gain
Peak
Power
(mW)
Calculated
Distance (m)
Minimum RF
Exposure
Separation
Distance (m)
Gabriel Parabolic SSG4-23 26.7 467.7 63 0.5 2
WARNING: It is the responsibility of the professional installer to ensure that when
using the outdoor antenna kits in the United States (or where FCC rules apply),
only these antenna configurations shown in the table above are used. The use of
any antenna other than those listed is expressly forbidden in accordance to FCC
rules CFR47 part 15.204.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment when installed as directed.
This equipment should be installed and operated with fix-mounted antennas that
are installed with a minimum separation distance of 2 meters (6.6 ft) or more from
all persons during normal operation to satisfy RF exposure requirements.
