MDR2400-SR, MDR5800-SR and Orion 5825-SR MDR2400-SR, MDR5800-SR and Orion 5825-SR Digital Radios User Manual Document Number: Issue 10 Page 1
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue Status Issue 1 2 3 4 5 6 7 8 9 10 Revised Pages/Amendments 1 31 2 General – terminology definition PER used instead of BER to remove interpretation ambiguity between Block Error Rate and Bit Error Rate. Note Block (equivalent to packet) concept is still maintained within sections describing G.826 parameters to maintain consistency with G.826 terminology.
MDR2400-SR, MDR5800-SR and Orion 5825-SR FEDERAL COMMUNICATIONS COMMISSION NOTICE The equipment has been tested and found to comply with the limits for a Class A digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Publication Number: 862-01881 Issue 10 March 2003 © 2003 Tellumat (Pty) Limited The information contained herein is the property of Tellumat (Pty) Limited and is supplied without liability for errors or omissions. No part may be reproduced, used or disclosed except as authorised by contract or other written permission.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Table of Contents Page 1 INTRODUCTION 10 1.1 Radio Description 10 2 TECHNICAL DESCRIPTION 14 2.1 2.2 System Overview Outdoor Unit 14 14 2.2.1 Frequency plans 15 2.2.2 RF Power Output Options 19 2.2.3 2.3 MDR2400, MDR5800 and Orion 5850 Outdoor Units Indoor Unit 19 20 2.3.1 Payload Interface Options 21 2.3.2 1+1 Redundancy Protected Payload System 21 2.3.3 Indoor Unit Status LEDs 21 2.3.4 Reset / Configuration Button 22 2.3.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4.1 4.2 Customer Furnished Tools and Equipment Indoor Unit 31 32 4.2.1 Introduction 32 4.2.2 Installing the Indoor Unit in a Rack 32 4.2.3 Connecting a DC Power Supply 33 4.2.4 Balanced Payload Data : DB25 34 4.2.5 Balanced Payload Data : RJ48 35 4.2.6 Unbalanced Payload Data : BNC 35 4.2.7 Connecting Auxiliary In/Out (Optional) 35 4.2.8 Connecting the Service (Wayside) Serial Channel (Optional) 36 4.2.9 4.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 8.1.1 Outdoor Equipment 52 8.1.2 8.2 8.3 8.4 8.5 Indoor Equipment Mechanical Information for Outdoor Equipment Mechanical Information for Indoor Equipment Power Supply Requirements Electrical Performance 52 52 52 52 53 8.5.1 General Characteristics 53 8.5.2 Transceiver Characteristics 55 8.5.3 RF Interface 56 8.5.4 Payload Data Interfaces 56 8.5.5 Ethernet Traffic Interface 56 8.5.6 Auxiliary Input Interface (CONTACT CLOSURE) 57 8.5.
MDR2400-SR, MDR5800-SR and Orion 5825-SR ORION5850 MDR2400 112 112 6 113 APPENDIX: USEFUL WEB LINKS 7 APPENDIX: MDR / ORION SCALABLE 1-TO-4/8 E/T1 / 10 BASE-T ETHERNET FUNCTIONALITY 114 8 APPENDIX: MDR / ORION FTP FIRMWARE UPLOAD 115 9 APPENDIX: GETTING STARTED GUIDE 117 Checklist for Bench Testing (without a PC) Interpretation Action 118 One Page Set-up for T1/E1 Bench Test (without a PC) 117 118 10 121 APPENDIX: 1+1 PROTECTION SYSTEM OPERATION 119 Introduction 121 System Description Te
MDR2400-SR, MDR5800-SR and Orion 5825-SR List of Abbreviations BIT AIS PER DC DCE DRL DRS DTE GUI IU ISM LED LOS Mbps N.C N.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 1 Introduction 1.1 Radio Description The MDR2400-SR and MDR5800-SR are ISM band digital radio systems that provide short to medium range, point-to-point digital communication with high data security at rates of T1, 2T1 or 4T1. Alternatively, the radio can be software configured to convey E1, 2E1 or 4E1. The radio can also be configured to bridge or route IP via a 10BaseT port.
MDR2400-SR, MDR5800-SR and Orion 5825-SR antenna via a coaxial transmission line. An optional indoor rack mounting adapter is available for mounting the OU, indoors. The system is available for use in FCC regulated countries.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Model variants Table 1. MDR2400 model variants Model Number Interfaces MDR2400-ET1 T1/E1 10BaseT Ethernet Antenna Coupling N-type Female 2 x T1 / 2 x E1 10BaseT Ethernet N-type Female MDR2400-ET4 4 x T1 / 4 x E1 10BaseT Ethernet N-type Female MDR2400-ET2 Table 2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue 10 Page 13
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2 Technical Description 2.1 System Overview A digital radio link (DRL) consists of a pair of MDR / Orion radio stations. MDR2400, MDR5800 or Orion 5850 OU MDR / Orion IU User Data MDR2400, MDR5800 or Orion 5850 OU MDR / Orion IU User Data The radio stations consists of two main parts: • An Outdoor Unit operating in the 2.4GHz or 5.8 GHz ISM frequency bands.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2.2.1 Frequency plans The MDR5800 and the Orion 5850 Outdoor Units operate in the 5.725 GHz to 5.850 GHz ISM frequency band with predefined frequency channel plans (termed A, B, C and D). Channel plan D is user selectable / adjustable. The MDR2400 Outdoor Units operate in the 2.400 GHz to 2.4835 GHz ISM frequency band with predefined frequency channel plans (termed A, B and D). Channel plan D is user selectable / adjustable. 2.2.1.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2.2.1.2 MDR2400 Frequency Channel Plan A, B (non-FCC) The channel spacing is based on the bandwidth occupied by the spread spectrum signal (approximately 17 MHz) and is used to optimise link performance. In the case of plan A and B, note that both Outdoor Units of a link must be set up to the same frequency channel plan (i.e. A or B). HIGH BAND TRANSMIT LOW BAND TRANSMIT AL 2410 BL 2426 AH 2458 BH 2474 Frequency (MHz) Figure 2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR The channel spacing is based on the transmit bandwidth, either 3 MHz, 6 MHz, or 10 MHz, software selectable. Different bandwidths can be selected dependent on the optimum link performance; required system sensitivity versus data transfer rate. Only channel frequencies that are FCC compliant can be selected through the configuration software. The channel frequency ranges are programmed into the radio firmware and cannot be adjusted by the user.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2.2.1.5 Frequency Channel Plan D (FCC Compliant) Frequency plan D allows independent control of transmit and receive frequencies. This allows a flexible frequency plan and can be used to overcome interference in the 2.4GHz and 5.8 GHz ISM bands. The frequencies that can be used in the lower or upper sub-bands can be selected in 1 MHz increments.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Table 7. Orion 5850 Modulator Types Data Rate [kbps] Modulation type Raw data throughpu t [bit/sec] Typical Payload Approx. OU output spectrum BW 8464 16-QAM 8 464 052 4T1/E1 + 150kbit Ethernet 2.6 MHz 16928 16-QAM 16 928 105 8T1/E1 + 150kbit Ethernet 5.4 MHz 25392 16-QAM 25 392 157 8T1/E1 + 9.5Mbit Ethernet 8 MHz NOTE 1: Changing the modulator type of an Orion 5850 Outdoor Unit may take up to 30 seconds.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2.3 Indoor Unit The Indoor Unit is designed for mounting in a 19” rack, occupying a 1U slot. It can also be used as a table-top system. The Indoor Unit accepts n x T1/nE1 user payload channels and combines it with Wayside Service Serial Data and IP data to be transmitted across the radio link. The Indoor Unit is fitted with a DC power supply.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Figure 5. Indoor Unit Connector Panels (numbers refer to paragraph number 2.3.x) 2.3.1 Payload Interface Options The Indoor Unit can be configured for nT1 or nE1 operation. h. 1, 2, 4 or 8(Orion 25) x T1 (1.544 Mbps) i. 1, 2, 4 or 8(Orion 25) x E1 (2.048 Mbps) For T1 connectivity, bipolar AMI or B8ZS line coding is software selectable. For E1 connectivity, bipolar AMI or HDB3 line coding is software selectable.
MDR2400-SR, MDR5800-SR and Orion 5825-SR In ALL cases flashing red and orange LEDs imply historic alarm conditions (The alarm can be cleared using the front panel button ‘position 1’ : see next section). Flashing LED’s and yellow indicators (Orion NMS) may also be cleared by clicking on the “Clear Alarms” button in the Orion NMS Main Radio Window. 2.3.4 Reset / Configuration Button The functionality of the Reset Button is described below. These functions are used to set up the radio.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 20. EEprom erased via front panel (MDR Only) 21. OU back-to-back enable / disabled toggle via front panel NOTE All buttons can be REACTIVATED (i.e. undoing a 14 'reset') by doing a poweron reset while holding the front-panel Reset Button in for 1 LED count.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2.3.7 10BaseT Ethernet RJ45 Port This port is used for communications with the NMS / GUI software from a laptop / PC or with an SNMP manger to control the system. It can also be connected to a hub for 10BaseT wayside Ethernet throughput. The interface type is DTE (Data Terminal Equipment) and can support Full and Half Duplex Ethernet connections. Select the Ethernet Duplex mode from the following MIB element: 1.3.6.1.4.1.1316.1.1.1.4.16 mdrmteEthernetFullDuplex.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2.3.12 IU DC Power Input This connector (socket) is used for power input to the IU. The connection is made using 2 or 3-core cable. The cable is connected to a two pin GREY connector on the MDR radio and a THREE pin GREEN connector on the Orion unit - both are plugs. The polarity-sense (labelled) must be observed and implemented. A ground connection is available on the three-pin connector.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 3 Planning This chapter is aimed at management and planning staff to enable them to assess the requirements for installing an MDR / Orion digital radio link. 3.1 System Type Selection The system uses an Outdoor Unit with a type-N RF output for connection to a range of antennas. The MDR / Orion is aimed at FCC regulated markets. Antenna polarization can used to co-locate multiple systems. Antenna polarization can be used to overcome interference. 3.1.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 3.2 Site Evaluation When planning a site for a digital radio link, it is of the utmost importance that you take the operational environment of the proposed site into account. The combined effect of atmospheric environmental factors such as rain and lightning, atmospheric attenuation, signal path obstruction, propagation fading, air temperature gradients, ice build-up, wind and solar radiation can contribute towards reducing the level of performance of the system.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 3.4 Interference Considerations The ISM frequency bands are used by other devices that can cause interference to the MDR / Orion radio systems. Interference can be avoided by careful planning of the system installation. The available methods for providing isolation from interfering radiators are the following: l. Frequency diversity m.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 3.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4 Installation This chapter describes a recommended installation procedure for the MDR2400, the MDR5800 and the Orion 5850. Before installation / departure to site 1. Carefully open all shipping boxes and look for any obvious damage that might have resulted during shipment. 2. Do an operational bench test to verify the functionality of the system.
MDR2400-SR, MDR5800-SR and Orion 5825-SR s. Installing the Indoor Unit (paragraph 4.2, page 32) t. Installing the Outdoor Unit and Antenna (paragraph 4.3, page 38) u. Installing the interconnection cables (paragraph 4.4, page 38) 4.1 Customer Furnished Tools and Equipment The following table lists tools and equipment required to install the MDR2400-SR, the MDR5800-SR and the Orion 5825-SR system. General, IU-to-OU Interconnect • • • • • Cable cutting and stripping tools. Ground lug crimp tools.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4.2 4.2.1 Indoor Unit Introduction This section describes the recommended installation procedure for the Indoor Unit. The Indoor Unit is designed for mounting in the DIN 41494 (19") racking standard and occupies a 1U high slot. Desktop mounting is also possible. The Indoor Unit’s payload (nT1, nE1 and 10BaseT Ethernet) and Service Channel (‘Wayside serial’) data interfaces and Element Management interface are located on the front panel.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4.2.3 Connecting a DC Power Supply WARNING – See section 0 for specification of the power supply. 1. 2. 3. Observing the polarity of the supply, wire up the supplied power connector cable plug and connect it to the DC supply (Voltage range as indicated on the Indoor Unit) through a minimum 2 A slow blow circuit breaker. Check the supply voltage using a multimeter. Secure the connector screws to the unit.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4.2.4 Balanced Payload Data : DB25 1. Assemble the (nE1) / (nT1) payload data input and output cable. See the table below for Indoor Unit connector pin assignments. 2. Connect the payload data cable to the DB25 connector on the front panel of the Indoor Unit. Standard termination of this port is 120 Ohms. On the Orion 25, 75 Ohms termination is available on request (please contact the factory).
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4.2.5 Balanced Payload Data : RJ48 1. Assemble the T1 / E1 payload data input and output cable. See the table below for Indoor Unit connector pin assignments. 2. Connect the payload data cables to the RJ48 connectors (numbered 1-8 for tribs 1-8) on the front panel of the Indoor Unit. Standard termination of this port is 110 Ohms. On the Orion 25, 75 Ohms termination is available on request (please contact the factory).
MDR2400-SR, MDR5800-SR and Orion 5825-SR Table 11. Auxiliary In/Out Connector Pin Outs Indoor unit connector 15-pin D-type female 8 1 15 4.2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR software or controlled via a PPP-dialup connection. The port can be connected to using the supplied serial data cable. The port is configured as DTE. NOTE The Ethernet 10BaseT port can also be used to control the IU via the GUI / SNMP software.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4.3 Outdoor Unit Before installing the MDR Outdoor Unit, ensure that a suitable mast is used for the antenna and that the Outdoor Unit installation is firmly in position. The pole diameter must be between 50 and 102 mm or between 2" and 4½". The Outdoor Unit may also be mounted indoors, utilizing an optional rack mount adapter (not included as a standard item) at the base of a tower for convenient access.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 1. 2. On the OU side, connect an RJ45 plug to the data cable. Place the RJ45 plug into the RJ45 socket in the Outdoor Unit connection box. On the OU side, connect the DC power leads within the Outdoor Unit Connection Box. Use the + and - connections. Rear Panel 1 IU/O U LINK 8 RJ45 Socket - + - + Front Panel 1 8 RJ45 Socket IU/OU LINK LOOKING AT THE "Outdoor Unit" CONNECTION BOX (Located on the rear panel of the MDR IU, front panel of the Orion IU) 3. 4.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4.4.
MDR2400-SR, MDR5800-SR and Orion 5825-SR This page is left blank intentionally.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 5 Antenna Alignment and Software Setup 5.1 This chapter describes the procedure for software setup and antenna alignment. The setup is done with a laptop / PC running the supplied NMS Graphical User Interface (GUI) software. See chapter 6 for details on using the NMS / GUI. Installation Equipment Required 5.2 The following tools and instruments are required for software setup and aligning the antenna: hh. RSSI test cable ii. Voltmeter jj.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Typical Version 2 MDR OU RSSI Voltage vs Received Signal Power (5.8GHz) Outdoor Unit RSSI Voltage 1.4 1.2 1 0.8 0.6 0.4 -80 -75 -70 -65 -60 -55 -50 -45 -40 -35 -30 Received Signal Power [dBm] Figure 7. Typical Version 2 MDR5800 OU RSSI Voltage as a function of RF input power level -80 dBm Average 0.436 ± 0.029 V : MIB RSSI 95 ± 1 dBm (see comment below) -30 dBm Average 1.333 ± 0.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Outdoor Unit RSSI Voltage Typical MDR2400 OU RSSI Voltage vs Received Signal Power 1.8 1.6 1.4 1.2 1 0.8 0.6 -100 -95 -90 -85 -80 -75 -70 -65 -60 -55 -50 -45 -40 Received Signal Power [dBm] Figure 8. Typical MDR2400 OU RSSI Voltage as a function of RF input power level (See comment above.) Typical Orion OU RSSI Voltage vs Received Signal Power Outdoor Unit RSSI Voltage 2 1.8 1.6 1.4 1.2 1 0.8 0.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 5.4 Software Setup Refer to chapter 6, for setting up the following: 5.5 oo. Payload interface. pp. Service Channel (Wayside) serial port. qq. Auxiliary in/out port. rr. General link parameters. Functional Test After completing the physical installation of the Indoor Units, antennas, Outdoor Units and the interconnection cables, you need to commission the system.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 5.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 5.7 MDR / Orion Test Record Parameter Unit Frequency channel plan: Transmit Receive NOTE 1 : C is NOT used for the MDR2400. NOTE 2 : FCC requirements (U.S. only), page 2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 6 NMS Software 6.1 Scope This section provides minimal information required to install the Orion NMS. A detailed HTML-based help document can be found on the NMS installation CD supplied with new radios. 6.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 6.4 • P III 450 MHz or higher CPU • 128 MB RAM • 20 MB Free Hard disk space • CD-ROM Drive • Win 98, 2000, NT or XP Operating System (Linux optional) Installing the NMS The NMS have been developed on the Java platform from Sun Micro Systems. This requires the installation of a Java Runtime Environment (JRE) on the PC from where the NMS will be used.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 6.5 Help documentation The HTML based help documents for the Orion NMS application is available on the installation CD at the following path: //OrionNMS/help/Orion NMS Help.htm. The help document can be accessed by opening it with an Internet browser of your choice. The help documents can also be opened from the Windows Start Menu folder created for the Orion NMS or through the Help|Contents menu in the Orion NMS application.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 7 Maintenance Information 1. The user is advised to refer to the Technical Data section (paragraph 8.5.10) for details on IU/OU interconnection cables (customer-furnished). 2. The “Ordering Information” paragraph in the Technical Data section (paragraph 8.6) provides details on part numbers for items that can be ordered. 3. Paragraph 4 of this manual lists customer furnished equipment that should be used for installing the MDR / Orion product. 4.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 8 Technical Data 8.1 8.1.1 8.1.2 8.2 Environmental Requirements Outdoor Equipment Operating temperature: -30°C to +60°C Relative humidity: 8-100% Atmospheric pressure: 0.7 to 1.06 kPa Lightning protection ITU-T K.20 Indoor Equipment Operating temperature: 0°C to +50°C Relative humidity: 5-90% Lightning protection: ITU-T K.20 Mechanical Information for Outdoor Equipment Dimensions (HxWxD): Weight: 8.3 8.4 335mm x 231mm x 124mm ~ 5.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 8.5 8.5.1 Electrical Performance General Characteristics MDR2400-SR Frequency Range: 2400 to 2483.5 MHz Payload Data Capacity: T1 (1.544 Mbps/s) / E1 (2.048 Mbps) 2T1 / 2E1 4T1 / 4E1 RF Channel Bandwidth: 17 MHz Go/Return spacing: Can be adjusted as fixed go-return spacing. NOT mandatory in the ISM licence-free bands.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Payload Data Capacity: Issue 10 • 1 - 4T1 (1.544 Mbps/s) / 1 - 4E1 (2.048 Mbps) (2.6MHz BW) • 1 - 8T1 (1.544 Mbps/s) / 1 - 8E1 (2.048 Mbps) (5.4MHz, 8.0MHz BW) RF Channel Bandwidth: (Selectable) 2.6MHz 5.4MHz 8.0MHz Go/Return spacing: Can be adjusted as fixed go-return spacing. NOT mandatory in the ISM licence-free bands. Modulation: 16-QAM Frequency Channel Plan A: 5731 and 5801 MHz (2.6MHz BW) 5732 and 5802 MHz (5.4MHz BW) 5734 and 5804 MHz (8.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 8.5.2 Transceiver Characteristics 8.5.2.1 Frequency Band: MDR2400 Lowband Outdoor Units Transmit band: 2410 – 2426 MHz (Centre frequency) Receive band: 2458 – 2474 MHz (Centre frequency) 8.5.2.2 Frequency Band: MDR2400 Highband Outdoor Units Transmit band: 2458 – 2474 MHz (Centre frequency) Receive band: 2410 – 2426 MHz (Centre frequency) 8.5.2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 8.5.3 8.5.4 RF Interface Transmitted Power +2 to+24 dBm – MDR2400 and MDR5800, +2 to +18 dBm – Orion 5850 standard output power, +2 to +24 dBm – Orion 5850 high output power, software adjustable (incl. mute) Receiver Sensitivity: Up to 4T1/4E1 : -6 -88dBm for BER = 10 (MDR2400) -6 -86dBm for BER = 10 (MDR5800) Up to 8T1/E1 : Orion 5850, 16 QAM -6 -85dBm for BER = 10 (2.6 MHz BW) -6 -82dBm for BER = 10 (5.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 8.5.6 8.5.
MDR2400-SR, MDR5800-SR and Orion 5825-SR The following table lists information to assist the user to select cables to be used between the Indoor and Outdoor Units. Interconnecting cable Data South Africa STP (FTP) 4 Pairs Solid Cat 5, PVC FR UV protected Polifin H2/J263/904 Outer Black. Outer diameter of cable : 7.3mm ± 0.5mm. (this is an “upjacketed” STP 4 Pair cable). This is a standard FTP Cat 5 cable that is ‘upjacketed’ with suitable plastic for FR/UV (Flame retardant/Ultra Violet) protection.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 8.6 Ordering Information To confirm the correct order numbers, please visit www.plesseybbw.com/download.htm to download an "Order Number Generator" utility. Part No 651-03994-01-H1 or 651-03994-01-L1 Model Number Description MDR2400-ET1 MDR2400 Radio: Indoor Unit (DB25 balanced payload) and High or Low Band Outdoor Unit, TypeN RF output, high power output, Full T1/E1, 2Mbps or 1.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 651-04055-02-H4 or 651-04055-02-L4 As above with BNC unbalanced payload also available. The MDR5800 operates from 21-56VDC (58VDC if indicated as such), optional 110-220VAC power supply available below. A complete link requires two radios, one must be High Band (HB) and the other a Low Band (LB).
MDR2400-SR, MDR5800-SR and Orion 5825-SR The MDR and Orion systems use standard CAT5 Ethernet cable and RJ-45 connectors for connecting the Indoor Unit to the Outdoor Unit. A two-wire power cable is also required between the Indoor Unit and the Outdoor Unit. NOTE Screened CAT-5 cable (for noise immunity) and UV resistant cables (for longterm outdoor use) are required to meet FCC EMC emission standards for this type of product.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Spare Parts for MDR2400, MDR5800 and Orion 5825 radios Part Number Description 651-04104-021 MDR MTE Indoor Unit 1xT1/E1 - Spare Part 651-04104-022 MDR MTE Indoor Unit 2xT1/E1 - Spare Part 651-04104-024 MDR MTE Indoor Unit 4xT1/E1 - Spare Part 651-04105-021 MDR MTE 75/120 OHM Indoor Unit (BNC) 1xT1/E1 Spare Part 651-04105-022 MDR MTE 75/120 OHM Indoor Unit (BNC) 2xT1/E1 Spare Part 651-04105-024 MDR MTE 75/120 OHM Indoor Unit (BNC) 4xT1/E1 Spare Part 65
MDR2400-SR, MDR5800-SR and Orion 5825-SR MDR2400 Ordering Information: Part no’s: 1T1/E1 Radio: 651-03994-01-H1 or 651-03994-01-L1 2T1/E1 Radio: 651-03994-01-H2 or 651-03994-01-L2 4T1/E1 Radio: 651-03994-01-H4 or 651-03994-01-L4 Each MDR2400 radio includes the following: Part No Description QTY 651-04104-02-1 MDR Indoor Unit: 1xT1/E1or 2xT1/E1 or 4xT1/E1, or 651-04104-02-2 120 Ohm or 651-04104-02-4 651-03905-01H MDR2400 ET4 Outdoor unit or 651-03905-01L 1 1 651-03809 MDR 5800 OU Pole Mounting Kit
MDR2400-SR, MDR5800-SR and Orion 5825-SR MDR5800 Ordering Information: Part no’s: 1T1/E1 Radio: 651-03853-02-H1 or 651-03853-02-L1 2T1/E1 Radio: 651-03853-02-H2 or 651-03853-02-L2 4T1/E1 Radio: 651-03853-02-H4 or 651-03853-02-L4 Each MDR5800 radio includes the following: Part No Description QTY 651-04104-02-1 MDR Indoor Unit: 1xT1/E1or 2xT1/E1 or 4xT1/E1, or 651-04104-02-2 120 Ohm or 651-04104-02-4 651-03806-02H MDR5800 Outdoor Unit or 651-03806-02L 1 1 651-03809 MDR 5800 OU Pole Mounting Kit 1 8
MDR2400-SR, MDR5800-SR and Orion 5825-SR Orion 5825-SR Ordering Information: Part no’s: 8T1/E1 Radio: 651-04230-01-H08 or 651-04230-01-L08 Each Orion 5825 radio includes the following: Part No Description 651-04231-0108 Orion 25 Indoor Unit: 8xT1/E1 QTY 1 651-04232-01H Orion 5850 Outdoor unit or 651-04232-01L 1 651-03809 MDR / Orion OU Pole Mounting Kit 1 862-01881 MDR / Orion Digital Radio System User Manual 1 651-04252 NMS Software CD 1 660-03405 RSSI Cable 1 Issue 10 Page 65
MDR2400-SR, MDR5800-SR and Orion 5825-SR 1 Appendix: Element Manager Port Point-to-Point Serial Communications Setup This appendix summarises how to set up a network connection (using PPP) between a computer and the MDR / Orion IU’s Element Manager port. It lists how the connection can be setup and configured to allow data transfer and SNMP-based control of the MDR / Orion IU. Note : For both NT and Win 95 or 98 machines, check that a Network Adapter is installed.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue 10 Page 67
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue 10 Page 68
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2. Select the COM port to use – push the Next when the COM port has been selected.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue 10 Page 70
MDR2400-SR, MDR5800-SR and Orion 5825-SR Adding Dial-up Networking : Windows NT To add dial-up networking 1. From the desktop, open the My Computer icon and double-click the Dial-up Networking icon. 2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 3. Whether COM1 or COM2 is selected, setup the connection using the following screens as a guideline. This allows establishment of a PPP connection between the computer and the IU’s Element Manager port.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue 10 Page 73
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue 10 Page 74
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue 10 Page 75
MDR2400-SR, MDR5800-SR and Orion 5825-SR Adding a Modem : Windows 95/98 1. When working with a PC running a Windows 95/98, add a modem using the following screen as a guideline. 3. Use the mdrnull.inf to add a serial cable modem connection capability to the PC or laptop.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 4. Once setup, use the following screens to set up the COM port’s parameters.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Adding Dial-up Networking : Windows 95/98 1. After adding the modem, set up the connection properties using the following screens as a guideline. This will allow establishment of a PPP connection between the computer and the IU’s Element Manager port. A Null_Modem connection option as shown below will be created. If one doesn’t exist, double click on the “Make New Connection” icon.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Issue 10 Page 79
MDR2400-SR, MDR5800-SR and Orion 5825-SR Adding Dial-up Networking : Windows 2000 / Windows XP To add dial-up networking The installation procedure documented here is based on the procedure that should be followed for Windows 2000. Some of the configuration windows for Windows XP may look slightly different, and may appear in a different order, but the basic procedure are the same as for Windows 2000 and are therefore not repeated in an attempt to reduce the size of this user manual. 1.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2. Select the Connect directly to another computer and press the Next button.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 3. Set the dialup connection to connect as Guest and press the Next button. Win2000 & Win-XP 4. Select the COM port you intend to use to connect to the radio from the Select Device dropdown box and press the Next button. In Windows XP, this window is preceded by Step 6 below.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 5. Select the users that must be able to use this dialup connection and press the Next button.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 6. Enter the name of this dialup connection and press the Finish button. This name may be any name of your choice. The connection is now installed, but its properties must still be configured. This window is displayed earlier in Windows XP. Win2000 & Win-XP 7.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 8. Browse to the newly added connection under the Network and Dial-Up connections menu item of Windows, and right-click on the connection with your mouse. Select the Properties item from the pop-up menu to bring up the properties window below. Now click on the Configure button below the Select a Device combo box in the General properties tab window to bring up the Modem Configuration box below.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 10. Browse to the newly added connection under the Network and Dial-Up connections menu item of Windows, and left-click on the connection with your mouse. This will bring up the connection window below. The values of the Username and Password fields does not matter, press Connect to dial into the radio once the dialup cable has been plugged into the Indoor Unit and the PC.
MDR2400-SR, MDR5800-SR and Orion 5825-SR 2 Appendix: MANAGEMENT OF THE MDR2400-SR MDR5800-SR and the Orion 5825-sr All management of the MDR and Orion products are implemented using SNMP (Simple Network Management Protocol), an open standard. The products can be managed by: 1. Standard SNMP managers such as HP OpenView or SNMPc i.e. there is Open Network Management compatibility. 2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR There are three principle requirements to use SNMP with the MDR / Orion Radio Stations. 1. A Management Station that runs a SNMP Management Software package that is installed on a networked or stand-alone PC that can be connected to an Indoor Unit either using a serial connection or an Ethernet connection. From the Management station, the agents within the Indoor Units can be configured or polled for information. 2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR The MIB Elements – OID (Object ID) DESCRIPTIONS Object ID Object name .1316 plessey .1316.1 products .1316.1.1 digitalradio .1316.1.1.1 mdrmte .1316.1.1.1.1 mdrmtePerformance .1316.1.1.1.2 mdrmteConfiguration .1316.1.1.1.3 mdrmteFault .1316.1.1.1.4 mdrmteAccess .1316.1.1.1.5 mdrmteRelayOutputs .1316.1.1.1.6 mdrmteOptoInputs .1316.1.1.1.1.1 mdrmtePayloadPerf .1316.1.1.1.1.1.1 mdrmtePpTable .1316.1.1.1.1.1.1.1 mdrmtePpEntry .1316.1.1.1.1.1.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Object ID Object name Access Object Type Rights .1316.1.1.1.1.2.3 mdrmteCurrentPER DisplayString read-only .1316.1.1.1.1.2.4 mdrmteMaximizedPER DisplayString read-only .1316.1.1.1.1.2.5 mdrmteLinkUnavailable INTEGER read-only .1316.1.1.1.1.2.
MDR2400-SR, MDR5800-SR and Orion 5825-SR Object ID .1316.1.1.1.1.3.1 Object name mdrmteStatus Access Object Type Rights Description INTEGER Indicates if 'G.826-like' errored, severely errored and unavailable read-only .1316.1.1.1.1.3.2 mdrmteTotalSeconds Counter read-only .1316.1.1.1.1.3.3 mdrmteAvailableSeconds Counter read-only .1316.1.1.1.1.3.4 mdrmteUnavailableSeconds Counter read-only .1316.1.1.1.1.3.5 mdrmteErroredSeconds Counter read-only .1316.1.1.1.1.3.
