Product Specs

Avi-on Product Specifications
Specifications
Input: Avi-on Direct Connect™ Low
Voltage DC Sensor Port
Dimensions: 2.30 in x 1.43 in x 0.75 in
(58.2mm x 36.4mm x 19mm)
Mounting: Acoustic tile clip included.
Magnetic mount for inside
xture mounting available. 4mm
M4 screw threads for mounting
clip by customer
Weight: 1.4 oz (40g)
Wiring: Direct Connect Cable: 3ft (1m)
-included and 10ft (3m) available
Operating Temp: -22F to +158F (-30C to +70C)
Storage Temperature: -40F to +185F (-40C to +85C)
Humidity Rating: 95% non-condensing
Programming: Via Avi-on platform. Mobile,
laptop, remote, local. Program
groups of sensors at once
Operating Modes: Occupancy, vacancy, UV-C safety, bi-
level, dim-to-specied level (never off ),
schedule driven, control zones or
individual xtures
Microwave Sensor: 360º hi resolution, low power
Time Delays: 15 sec - 1h 30 min adjustable via
network (20min default)
Status LED: On motion detection. Fixture light
ashes on motion in test mode
Daylight Harvesting: Open or closed loop (0-1020 Lux)
Daylighting Range: 360º x 90º
Spacial Coverage: 90º
Height Range: 8ft-15ft (2.5m-4.2m)
IP Rating: None
Warranty: 5 years, 10 years optional
* Note: Operating controller at or above these levels may result in damage to components/product
Diagrams
Wiring Diagrams
Dimensions
Note: Use supplied ribbon cable to directly connect the Avi-on AVI-DC-MW sensor to an Avi-on lighting device.
