9600 Series User Guide Page 64

Issue 05d (Wednesday, March 07, 2012)B5800 Branch Gateway

11.3 Viewing Call Details

You can view additional details about the currently shown call.

1.Access the call log.

a. Press the HISTORY button.

b.The display will change to show your call log records. The caller's name is shown if known, otherwise the

number. If you have any new missed call records, the button is illuminated and the call log will open showing

your missed calls.

c. Use the left and right arrow keys to select which call log records you are viewing. The options are All,

Outgoing , Incoming and Missed . On touch screen phones, press the icon for the type of call

log records you want to display.

d.Use the up and down arrow keys to scroll through the records.

2.Press the Details soft key. The individual details of the currently selected call record are displayed.

3.The possible values are:

Name

Call Type Icon

Number

Count

Time and Date

Duration

· Name - The name of the caller if known.

· Number - The number of the caller if available.

· Time and Date - The time of the call.

· Call Type Icon - The type of call record, ie. = Incoming, = Outgoing or = Missed.

· Count - How many time a call of the same type, name and number has occurred. Only the details of the most

recent call are kept in your call log. However the count will indicate if the caller has rung or has been rung

several times.

· Duration - The length of the call.

4.While you are in the details of a call record, the soft key functions available are:

· Call

Call the number shown in the call record. You can also do this by pressing the OK button.

· List

Go back to the normal call screen to select another call record. You can also use the up and down arrow

keys to view the previous or next record.

· Delete

Delete the currently displayed record.

· More

Switch between the different sets of available soft key functions.

· +Contact

Add the name and number to your personal directory. You can edit the details before they are added.

· Delete All

Delete all the records.
