9600 Series User Guide Page 50

Issue 05d (Wednesday, March 07, 2012)B5800 Branch Gateway

9. Headset/Handsfree Operation

9.1 Headset Operation

Your phone has a headset socket located under the phone. This is suitable for the connection of phone headsets that

connect via an HIS headset cable.

· Pressing the HEADSET key can be used to answer a call through the headset. It can also be pressed to end a

headset call.

· The key is lit when there is a call connected through the headset.

· The key can also be pressed to turn a call that has already been answered using the handset or handsfree into a

headset call.

· If there are no currently connected calls to which you are talking, a call answered by pressing its appearance

button is connected either handsfree or through the headset according to the phone's audio path setting .

· If there is already a connected call to which you are talking through the headset, answering another call by

pressing the appearance button will answer that call using the headset.

You can adjust the following handsfree settings:

· Headset Volume

· Headset Automatic Gain Control On/Off

· Default Audio Path

9.1.1 Headset Volume

While talking via the headset, you can adjust the volume of the incoming call. The status indication line displays a icon

followed by eight bubbles that represent the volume level.

1.With the call connected on the headset, press the key.

2.Use the + plus and – minus keys to adjust the volume.

3.The display returns to normal after a few seconds.

9.1.2 Default Handsfree Audio Path

By default, when you make a call or answer a call without lifting the handset, the audio is played through the phone's

speaker while you speak via the phone's microphone.

If you have a headset attached, you can change the phone's behavior so that the audio is played through the headset by

default rather than the speaker.

1.Press the MENU/HOME button and select Settings.

2.Use the up and down arrow keys to highlight Options & Settings. Press Select.

3.Use the up and down arrow keys to highlight Call Settings. Press Select.

4.Use the up and down arrow keys to highlight Audio Path.

5.Press Change to change the setting between Headset and Speaker.

6.When completed, press the Save soft key.

7.Press the Back / Exit soft keys to exit the menus.
