9600 Series User Guide Page 121

Issue 05d (Wednesday, March 07, 2012)B5800 Branch Gateway

Phone Settings: Display Controls

18.7 Volume and Sound

This section covers controls that relate to volume and to the various sounds that your phone uses. These are in addition

to the available ringer controls .

· Button Click

Turn the phone menu key click on or off.

· Error Tones

Turn the phone menu error tones on or off.

· Ringer Volume

Adjust the volume of the ringer used by the phone.

· Handset Volume

Adjust the incoming call volume heard through the phone's handset.

· Headset Volume

Adjust the incoming call volume heard through a headset attached to the phone.

· Speaker Volume

Adjust the incoming call volume heard through the phone's speaker.

· Automatic Gain Control

Switch automatic gain control on or off.

Note: The system administrator can configure your phone to reset its volume after each call.

18.7.1 Button Clicks

While using the phone menus, the phone can provide a key press confirmation click sound. This can be disabled.

1.Press the MENU/HOME button and select Settings.

2.Use the up and down arrow keys to highlight Options & Settings. Press Select.

3.Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.

4.Use the up and down arrow keys to highlight Button Clicks.

5.Press Change to change the setting between On or Off.

6.When completed, press the Save soft key.

7.Press Back / Exit to exit the menus.

18.7.2 Error Tones

1.Press the MENU/HOME button and select Settings.

2.Use the up and down arrow keys to highlight Options & Settings. Press Select.

3.Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.

4.Use the up and down arrow keys to highlight Error Tones.

5.Press Change to change the setting between On or Off.

6.When completed, press the Save soft key.

7.Press Back / Exit to exit the menus.

18.7.3 Ringer Volume

You can adjust the ringer volume while the phone is idle or while it is ringing. The status indication line displays a icon

followed by eight bubbles that represent the volume level. When no ringer is audible, the indication line displays a

icon.

1.With the phone idle or ringing, press the key.

2.Use the + plus and – minus keys to adjust the volume.

3.The display returns to normal after a few seconds.
