9600 Series User Guide Page 117

Issue 05d (Wednesday, March 07, 2012)B5800 Branch Gateway

Phone Settings: Display Controls

18.6.1 Display Brightness

1.Press the MENU/HOME button and select Settings.

2.Use the up and down arrow keys to highlight Options & Settings. Press Select.

3.Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.

4.Use the up and down arrow keys to highlight Brightness. Press Select.

5.Use the left and right arrow keys to adjust the brightness as required.

6.When completed, press the Save soft key.

7.Press Back / Exit to exit the menus.

18.6.1.1 Display Contrast

1.Press the MENU/HOME button and select Settings.

2.Use the up and down arrow keys to highlight Options & Settings. Press Select.

3.Use the up and down arrow keys to highlight Screen & Sound Options. Press Select.

4.Use the up and down arrow keys to highlight Contrast. Press Select.

5.Use the left and right arrow keys to adjust the brightness as required.

6.When completed, press the Done soft key.

7.Press Back / Exit to exit the menus.

18.6.2 Last Call Duration Display

As an alternate to call timer display, you can have the phone briefly (4 seconds) display the duration of the call after

it is ended.

1.Press the Features soft key if shown. To do this during a call, press the PHONE key and then press the

Features soft key.

2.Use the up and down arrow keys to highlight Call Settings. Press Select.

3.Use the up and down arrow keys to highlight Show Last Call Duration.

4.Press Change to change the setting between On or Off.

5.Press the Save soft key.

118
