INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES Model Number/ No. de Modelo: WC 602D WINE/BEVERAGE COOLER REFRIGERADOR PARA BOTELLAS DE VINO/CERVEZA Y SODAS BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. La sección en español empieza en la página 17. Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice. Avanti Products, A Division of The Mackle Co., Inc. P.O.
REFRIGERATOR SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual for your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages will follow the Safety Alert Symbol and either the words” DANGER”, “WARNING” or “CAUTION”.
IMPORTANT SAFEGUIDES Before the refrigerator is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the refrigerator, follow basic precaution, including the following: ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Plug into a grounded 3 -prong outlet, do not remove grounding prong, do not use an adapter, and do not use an extension cord.
REGISTRATION INFORMATION Thank you for purchasing this fine Avanti product. Please fill out this form and return it within 100 days of purchase and receive these important benefits to the following address: Avanti Products, A Division of The Mackle Co., Inc. P.O.Box 520604 – Miami, Florida 33152 ? Protect your product: We will keep the model number and date of purchase of your new Avanti Products product on file to help you refer to this information in the event of an insurance claim such as fire or theft.
HELP US HELP YOU... Read this guide carefully. Write down the model a nd serial numbers. It is intended to help you operate and maintain your new Wine/Beverage Cooler properly. You'll find them on a plate located on the rear wall of the Wine/Beverage Cooler Keep it handy to answer your questions.
PARTS & FEATURES 1. 2. 3. 4. 5. 6. 7.
T ABLE OF CONTENTS REFRIGERATOR SAFETY _________________________________________________________2 IMPORTANT SAFEGUIDES________________________________________________________ 3 REGISTRATION INFORMATION____________________________________________________ 4 HELP US HELP YOU…________ ____________________________________________________6 PARTS AND FEATURES __________________________________________________________7 IMPORTANT SAFETY INSTRUCTIONS_______________________________________________9 INSTALLATION INSTRU
IMPORTANT SAFETY INSTRUCTIONS ? WARNING? ? ? ? ? ? ? To reduce the risk of fire, electrical shock, or injury when using your Wine/Beverage Cooler, follow these basic precautions: Read all instructions before using the Wine/Beverage Cooler. DANGER or WARNING: Risk of child entrapment. Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are still dangerous . . . even if they will “just sit in the garage a few days”.
? After plugging the appliance into a wall outlet, allow the unit to cool down for 2-3 hours before placing items in the compartment. ? Electrical Connection ? Warning? Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized Avanti Products service center. This unit should be properly grounded for your safety.
COLD: FOR BEER OR SODA CANS SPARKL: SPARKLING WINES/ROSE WINES WHITE: WHITE/DRY WINES RED: RED WINES 39º -40º F 41º-47ºF 48º-57ºF 58º-65ºF NOTE: WHEN USING FOR BOTH WINE AND BEER SIMULTANEOUSLY WE RECOMMEND THAT YOU PLACE RED WINE BOTTLES ON TOP SHELF AND BEER ON BOTTOM SHELF.
CARE AND MAINTENANCE ? Cleaning Your Wine/Beverage Cooler ? Unplug the Wine/Beverage Cooler, and remove all items including shelves and rack. ? Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. ? Wash the shelves and rack with a mild detergent solution. ? The outside of the Wine/Beverage Cooler should be cleaned with mild detergent and warm water.
PROBLEMS WITH YOUR WINE/BEVERAGE COOLER? You can solve many common Wine/Beverage Cooler problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. TROUBLESHOOTING GUIDE PROBLEM Wine/Beverage Cooler does not operate. POSSIBLE CAUSE Not plugged in. The circuit breaker tripped or a blown fuse. Check the temperature control setting. External environment may require a higher setting. The door is opened too often.
SERVICE FOR YOUR WINE/BEVERAGE COOLER We are proud of our customer service organization and the network of professional service technicians that provide service on your Avanti Products appliances. With the purchase of your Avanti Products appliance, you can be confident that if you ever need additional information or assistance, the Avanti Products Customer Service team will be here for you. Just call us toll-free.
YOUR Avanti Products WARRANTY Staple your sales receipt here. Proof of original purchase date is needed to obtain service under warranty. WHAT IS COVERED LIMITED ONE-YEAR WARRANTY LIMITED SECOND THROUGH FIFTH YEAR WARRANTY For one year from the date of purchase by the original owner, Avanti Products will, at its option, repair or replace any part of the unit, which proves to be defective in material or workmanship under normal use.
WIRING DIAGRAM 16
INSTRUCCIONES EN ESPAÑOL PRECAUCIÓN ? ? ? ? ? ? ? Para reducir el riesgo de incendio, descarga eléctrica, o daño cuando use su electrodoméstico, siga las siguientes precauciones. Lea todas las instrucciones antes de usar su electrodoméstico. Peligro o Precaución: Existe el riesgo que los niños queden atrapados. Niños atrapados o sofocamiento no son un problema del pasado. Los electrodomésticos son peligrosos aún si solo los deja en el garaje por un par de días.
Un refrigerador vacío es una atracción muy peligrosa para los niños. Quite los sellos magnéticos, puertas o cerraduras de todo electrodoméstico que esté en uso. ? OPERACION Enchufe el cable a la toma de corriente, que debe ser 115 -120V, A.C.~ 10 AMP ó más. Para evitar vibraciones, la caja debe estar bien nivelada. Al conectar su vinera por primera vez, puede haber una variante de varios grados entre la temperatura seleccionada y la indicada en la activación y desactivación.
IRREGULARIDADES CON EL FUNCIONAMIENTO DEL REFRIGERADOR PROBLEMA El electrodoméstico no funciona. CAUSAS PROBABLES Falta de energía. Enchufe desconectado. La refrigeración es insuficiente. Botón de control de temperatura en la pos ición incorrecta. Elevada frecuencia de apertura de la puerta. Expansión del gas en el evaporador. Tubos en contacto con gabinetes o paredes. Ruidos anormales. SOLU CION Verifique el fusible. Substitúyalo o arréglelo. Coloque el botón en la posición correcta. Conéctelo.
