User guide

EBM-CX700 Series
16 EBM-CX700 Series Quick Installation Guide
2.4.3 Setting Connector
USB 1.1/2.0 Connector 1 (DJP1) Audio Connector (DJP2)
Signal PIN PIN Signal
+5V 1 2 GND
D1- 3 4 GND
D1+ 5 6 D2+
GND 7 8 D2-
GND 9 10 +5V
Note: Wrong USB cable
configuration with your USB
devices might cause your
USB devices damaged.
Signal PIN PIN Signal
LINEOUT_R 1 2 LINEOUT _L
GND 3 4 GND
LIN_R 5 6 LIN_L
Mic In 7 8 Mic Bais
LINEOUT_JD 9 10 LINEIN_JD
MIC_JD 11 12 GND
Power & HDD & LAN LED Indicator
Connector (DJP3)
Power Button Connector (DJP4)
Signal PIN PIN Signal
GND 1 2 DPWLED
DHDLED 3 4 DHDPW
DACT_LAN1 5 6 DPWLAN1
DACT_LAN2 7 8 DPWLAN2
Signal PIN
DPW_BN 1
GND 2
Line Out Connector (DLO1)
Signal PIN PIN Signal
DAUD_OUTL 1 2 GND
DAUD_OUTR 3 4 GND
