AW900mTRUser’s Manual
To add a new SU to the AP, disconnect the AP from the network and power o.
Connect an Ethernet cable between the SU and AP. Power up the SU FIRST and then
the AP. The SU will receive the key. Disconnect the Ethernet cable and cycle power
on the SU to cause the new keys to take eect.
To re-key SUs to a new AP, proceed as in the inital setup, making sure to power up
the AP FIRST.
Technical specications
Characteristic Specication/Description
RF transmission rate 1.536 Mbps
Ethernet data rate 935 Kbps
Output Power +21 dBm (4 Watts EIRP with 15 dBi antenna)
Receive Sensitivity -97 dBm at 10
-4
Bit Error Rate
Range Up to 40 miles line-of-sight with 15 dBi antennas
RF channels/bandwidth 12 non-overlapping with 2.0833 MHz spacing and 1.75 MHz
bandwidth
Channel selection Automatic or manual via DIP switches or browser interface
Adjacent band rejection SAW receiver lter attenuates cellular and pager interfer-
ence
Error correction Sub-block error detection and retransmission
Encryption 128-bit AES, meets FIPS 197 Standard
Browser Management Tools QoS statistics, network settings, spectrum analyzer
Status LEDs Power, RF activity, Ethernet connect, channel, link quality
Connectors RF: RPSMA Female, Ethernet: RJ-45, Power: P5, 2.1 mm ID
Power consumption Transmit: 1.7 Watts, Receive: 0.8 Watts
Voltage 9-48 VDC, power over Ethernet pins 4,5 positive, 7,8
ground or via separate P5 jack
Power regulation Switching regulator
Transmit current draw 175 ma at 9 VDC
140 ma at 12 VDC
35 ma at 48 VDC
Operating Temperature Range -40 ºC to +80 ºC
Size 70 by 66 by 23 mm, 40 grams
