User's Manual

LED display:
The AW900m has a 16 LED display to display the status of the device.
LED Name Function Color
1 Power Unit has power and has successfully booted. Red
2 RF Link The radio has successfully linked with it partner. Green
3 RF TX Radio transmission is occurring. Green
4 RF RX Radio reception is occurring. Green
5 Eth Link The Ethernet Port has a valid Ethernet connection Green
6 Activity The AW900m is processing data Green
7 1 (channel)
8 2 (channel)
9 4 (channel)
10 8 (channel)
By adding the numbers that are lit the user can
determine the current radio channel.
1 903 MHz 7 915 MHz
2 905 MHz 8 917 MHz
3 907 MHz 9 919 MHz
4 909 MHz 10 921 MHz
5 911 MHz 11 923 MHz
6 913 MHz 12 925 MHz
Green
11 Link Quality Excellent link quality –
No retransmissions
Green
12 Link Quality Very good link quality –
Few retransmissions
Green
13 Link Quality Good link quality –
Occasional retransmissions
Amber
14 Link Quality Fair link quality –
Some retransmissions
Amber
15 Link Quality Poor link quality –
Many retransmissions
Red
16 Link Quality No link quality
No link available
Red
Troubleshooting:
See the online installation tutorial and FAQ at
www.avalanwireless.com
No Power LED:
Check the power connections.
No Radio Link LED:
The radio is looking for its matched partner. If both units are powered up and the Power LEDs
are active they may be too far away to create the radio connection. Try other locations that
may have a less obstructed path or try to reorient the antennas.
Yagi type antennas get their best range when they are oriented to point directly at each
other with the antenna elements oriented in the same plane (eg. vertically or horizontally)
Radio LINK LED on but Link Quality Indicator is low:
The units may be too far away to create a good radio connection. Try other locations that
may have a less obstructed path or try to reorient the antennas.
No Ethernet LINK LED:
Check your network connections.
Installing Multiple systems in close proximity:
See the online installation tutorial and FAQ at
www.avalanwireless.com
Still not working?
Temporarily use an Ethernet cable to see if the network is working over a wired connection.
If an Ethernet cable does not work then the problem is with the network.
Support Email: [e-mail] Support helpline: [phone]
