In the Event of a Fire Alarm -
with Alarm Delay
Operator's Handbook, AutroSafe Interactive Fire Alarm System, Release 3, ASAFE-FB/FE Rev. A, 010531,
Autronica Fire and Security AS
Page 20
5.4 Actions to be Taken - Fire Alarm with Alarm Delay
Step Actions to be taken Display Indication Audible Indication
1
Follow all precautions
described in the local
fire instructions, step by
step.
1* KITCHEN
FIRST DELAYED OUTPUTS ACTIVATES 19:30
FIRE ALARMS
19:23
Total: 1
The internal buzzer on
the Repeater Panel is
turned on.
Comments:
The red FIRE indicator starts to blink.
The FUNCTION DELAYED and FUNCTION DISABLED indicators have a
steady yellow light indicating that Immediate Output Actioning has been
disabled (manual operation in Menu Mode by means of the Fire Alarm
Control Panel BS-320 or the Operator Panel BS-330).
In this example, one point in a Delayed Action detection zone is signalling an
alarm.
2
To silence the internal
buzzer, press the black
Mute Panel button
1* KITCHEN
FIRST DELAYED OUTPUTS ACTIVATES 14:40
FIRE ALARMS
19:23
Total: 1
The internal buzzer on
the Repeater Panel is
turned off.
3
Observe the zone(s) in
alarm state in the
display.
Investigate the scene(s)
and carry out the
necessary actions.
1* KITCHEN
FIRST DELAYED OUTPUTS ACTIVATES 14:40
FIRE ALARMS
19:23
Total: 1
4
The next step in the procedure will depend on whether or not there really is a fire.
Follow if there is not
a fire - or follow if there really is a fire.
4a
If there is not a fire,
press the green Reset
button.
RESET
19:23
Total: 3
19:23
AUTROSAFE
SelfVerify
Comments: The red FIRE indicator goes off.
The idle display is shown.
4b
If there really is a fire,
activate the nearest
manual call-point or go
to the nearest operator
panel (BS-320/330) to
activate the alarm.
Implement the
necessary measures.
FIRE ALARMS
19:23
Total: 1
1 KITCHEN
All fire alarm devices
within the operation
zone of the panel
(sounders and visual
indicators) are
activated.
Comments: The red Fire Brigade Signalled indicator is lit.
If the delay time expires, all fire alarm devices within the alarm zones
assigned to the actual detection zones (sounders and visual indicators)
will automatically be activated.
