In the Event of a Fire Alarm -
with Alarm Delay
Operator's Handbook, AutroSafe Interactive Fire Alarm System, Release 3, ASAFE-FB/FE Rev. A, 010531,
Autronica Fire and Security AS
Page 19
Power
Fire Brig. Signalled
Function Delayed
Function Disabled
Mute Panel
Silence Alarms
Reset
More Events
Fault
ALARM
In the Event of a Fire Alarm -
with Alarm Delay
5.3 Indications - Fire Alarm with Alarm Delay
The following shows the indications on the Repeater Panel in the event
of «Fire Alarm with Alarm Delay» within the operation zone of the
panel.
The internal buzzer is
activated.
Default pattern on the
sound:
1 sec. ON, 1 sec. OFF
A point set to Delayed Action (configurable) is sending an alarm signal from a Delayed Action
detection zone in a situation where Immediate Output Actioning has been disabled, i.e. the alarm
delay has been activated.
NOTE:
An alarm from a manual call-point is normally configured to give immediate actioning on the
alarm outputs even though the Immediate Output Actioning has been disabled.
The text display indicates the detection zones in alarm state and their
location, plus the activation time of the delayed outputs.
The red Alarm indicator is
blinking.
The Function Delayed
indicator has a steady
yellow light.
The Function Disabled
indicator has a steady
yellow light.
