3.5 How Fire Alarms are Presented in the Display
Fire alarms are presented in Operation Mode. FIRE ALARMS is shown
in the upper left corner of the display.
The example below shows a situation where three zones are in alarm
state. The total number of zones in alarm is shown in the upper right
corner.
1 OFFICES
2 CANTEEN
3 WORKSHOP
FIRE ALARMS
19:23
Total: 3
Header Time
Total
number of
fire alarms
Detection
Zone(s) in
fire alarm
Figure 3-2: How fire alarms are presented
