The Repeater Panel - Overview
Operator's Handbook, AutroSafe Interactive Fire Alarm System, Release 3, ASAFE-FB/FE Rev. A, 010531,
Autronica Fire and Security AS
Page 8
Power
Fire Brig. Signalled
Function Delayed
Function Disabled
Mute Panel
Silence Alarms
Reset
More Events
Fault
AUTROSAFE
SelfVerify
ALARM
2.4 Operating Buttons
Front Push Buttons
Front Push Buttons
Button Designation Access
Level
Mute Panel
(black)
Used to mute the panel. Timeout. 1
Silence Alarms
(red)
Used to silence Fire Alarm Devices (FAD) and cause
blinking serial numbers and lamps to go steady.
Timeout.
Also used to resound (repress the SILENCE ALARMS
button) after the silence function has been activated
2
Reset
(green)
Used to reset the system.
Can also be used as an accept of alarm (points)
disablement, if points are still in alarm when RESET is
activated.
If the button is pressed more than 5 seconds, a lamp
test is performed (Access Level 1, no key or
password required).
2
v
v
More Events
(black)
Used to scroll downwards among alarms in window
(scroll page by page). Possible only if there are more
alarms than possible to display in the window.
1
Reset
(green)
Silence Alarms
(red)
Mute Panel
(black)
More Events
v
v
More Events
(black)
