2.5.2 Auto Intermittent Filtration Components
2.5.2.1 LOV™ Indicator Lights Assembly
ITEM PART # COMPONENT
1 106-8106SP Light, Blue 24VDC LED Flush
2 106-8105SP Light, Yellow/Orange 24VDC LED Flush
3 230-4271 Plate, Control Frame LOV™
2.5.2.2 Manual Interface Board Assembly
ITEM PART # COMPONENT
1 230-4868 Cover, MIB
2 106-9246 Assembly, MIB Computer w/ Frame
106-9609SP Board, PCB MIB
807-4481 Overlay
3 106-9643 Assembly Back, Box MIB
106-8231SP LOV™ Panel Assembly
106-9642 Manual Interface Board Assembly
