Specifications

2-13
2.4.3.2 Element Tube Assemblies contd.
ITEM PART # COMPONENT
1 106-7653SP Tube Assembly RE Element, Full-Vat
2 106-7654SP Tube Assembly RE Element, Dual-Vat
3 810-3246 Bushing and Tube Assembly, Dual-Vat
4 106-5329 Bracket Assembly, LH Element Tube Support
5 106-5330 Bracket Assembly, RH Element Tube Support
6 220-0122 Plate, Element Tube Support Inner
7 220-0123 Plate, Element Tube Support Outer
8 106-7651 Bracket Assembly, LH Upper Spring (use 106-6569 for 17kW)
9 106-7652 Bracket Assembly, RH Upper Spring (use 106-6570 for 17kW)
10 810-2992 Tube, Full Vat Element Mounting
11 810-2993 Bushing, Tube End Teflon
* 106-6587 Magnetic Position Sensor Assembly
* 826-2228 Magnetic Position Sensor Assembly with Bracket
* 810-3007 Magnet
* 230-0794 Bracket, Magnetic Position Sensor Wire
* Not illustrated.
2.4.4 Computers
ITEM PART # COMPONENT
Replacement Computer
106-8195SP Non-CE Domestic M2007 (For use in US, Canada, Mexico and all
other non-CE countries)
106-8197SP CE M2007 Full Vat (For use in European CE countries)
NOTE: See Page 2-17 for Interface Board to Computer Wiring Harness
