2.4.2.1 Left and Right Contactor Box Configurations
NOTES: Left and right contactor box assemblies are mirror images of one another. With the
exception of the box itself, all components of a left-hand assembly are the same as those in the
corresponding right-hand assembly and vice versa except for the hood relay which occurs in the
right or large box only. The configurations illustrated show all possible components, but a particular
configuration may not have all the components shown.
ITEM PART # COMPONENT
1 106-8658 Box Assembly, Left Contactor
2 823-6538 Box Assembly, Left Contactor EPRI
3 106-8660 Box Assembly, Right Contactor
4 823-6539 Box Assembly, Right Contactor EPRI
5 810-2554 Plug, Cord Cutout 1.125 Button
6 807-1947 Plug, .875 Diameter Dome
7 221-0482 Cover, Left Hand Contactor Box
8 222-0482 Cover, Right Hand Contactor Box
9 807-0070 Terminal, Ground Lug
10 807-1071 Contactor, 24V 30 Amp Mercury (Heat)
11 807-0884 Contactor, 24V 50 Amp Mercury (Heat)
12 807-2284 Contactor, 24V 50 Amp Mechanical (Heat)
13 807-2283 Contactor, 24V 63 Amp Mechanical (Heat)
14 810-1202 Contactor, 24V 40 Amp Mechanical (Latch)
15** 806-8674 Heatsink Assembly, DV Solid State Relay (See components below)
16** 806-8673 Heatsink Assembly, FV Solid State Relay (See components below)
Components of Items 15 and 16
17 826-1562 Kit Relay, Solid State 40 Amp 280V with Heatsink
18 807-2749 Heatsink, Solid State
19 807-0037 Terminal, ¼-inch Push-on
20 807-1683 Relay, Hood 12VDC
21 221-0482 Cover, Left Contactor Box Top
22 222-0482 Cover, Right Contactor Box Top
23 106-6204 Filter Assembly, EPRI (used in CE WYE-configured EPRI units only)
24 807-4316 McDonald’s Cordset, 120V 5-Wire
25 807-4317 McDonald’s Cordset, Europe 3-Wire Single Phase
26 807-1560 Strain Relief
27 220-1102 Plate, MRE Control Cord Relief
28 807-0064 Transformer, 480V/120V 150VA
29 807-0922 Holder, Bus Fuse
30 807-2278 Fuse, 20 Amp
* 221-0610 Bracket, Left Hand Contactor Box Mounting
* 222-0610 Bracket, Right Hand Contactor Box Mounting
* 807-0012 Relay, Tilt Switch 18 Amp 1/3 HP 24 V Coil
* Not illustrated.
** Dual-vat assembly has six relays (826-1562); Full-vat assembly has three relays.
