Specifications

2-2
2.2 Doors, Sides, Tilt Housings, Cap-N-Splash, Top Caps and Casters
ITEM PART # COMPONENT
1 231-0323 Side, Standard Cabinet Left SS (use 221-0323 for Enameled Steel)
2 232-0323 Side, Standard Cabinet Right SS (use 222-0323 for Enameled Steel)
3 810-1105 Magnet, Door (vertical) (use 810-2346 for horizontal over filter pan)
4 106-4397 Door, Left or Right (Left shown – move handle to bottom for right)
5 230-4960 Handle, Eurolook Door
6 106-4067 Pin Assembly, Door
* 810-0275 Spring, Door Pin
* 809-0970 Retaining Ring
* 230-4685 Hinge, Door Lower
7 810-0327 Caster without Brake
8 810-0326 Caster with Brake
9 Tilt Housing (Housing for five station fryer shown)
823-6085 Two Station, S/S (use 823-6460 for Aluminized Steel)
823-5700 Three Station, S/S (use 823-6461 for Aluminized Steel)
823-6151 Four Station, S/S (use 823-6462 for Aluminized Steel)
823-6243 Five Station, S/S (use 823-6885) for Aluminized Steel)
10 Cap-N-Splash
823-6420 Two Station
823-6421 Three Station
823-6422 Four Station
823-6887 Five Station
11 Top Cap (Top cap for five station fryer shown)
106-7835 Two Station (Also requires four 809-0078 10-32 Nutserts)
106-5979 Three Station (Also requires six 809-0078 10-32 Nutserts)
106-7576 Four Station (Also requires eight 809-0078 10-32 Nutserts)
106-7841 Five Station (Also requires ten 809-0078 10-32 Nutserts)
* Not illustrated.
