1 Ground Black
2 CAN Lo Red
3 CAN Hi White
4 5VDC+ 5VDC Black
5 24VDC 24VDC Red
J2 AIF J4 8074547
6 Ground White
J3 SD Card
1 Momentary Switch - Out 5VDC Red
RTI - JIB Fill Switch
2 Momentary Switch - In 5VDC Black
3 Ground Red
J4
Reset Switch
4 Reset Green
1 24VAC Black
Transformer
2 24VAC Ret
24VAC
White
3 Pump Motor Red
Filter Relay
4 Pump Motor
24VDC
Green
5 Blue LED + Black
Blue LED
6 Blue LED -
24VDC
White
7
8
9
10
11 Pan Sw + Black
Pan Switch
12 Pan Sw -
24VDC
Red
13 Ground
14 Ground
15
J5
8074649
16
1 From RTI transformer 24VAC Black
2 Common White
3 To RTI "Add Pump" Relay 24VAC Green
4 To Waste Solenoid - 3 Way 24VAC Brown
5
6 To Fill Solenoid - 3 Way
24VAC
Black
7 Ground - Fill Solenoid Black
J6
RTI - Pump &
Solenoids
8
From RTI "Waste Tank Full
Sensor" Test Pins 1 to 8
24VAC –
Full
0VAC –
Not Full Red
1 From RTI transformer 24VAC Black
2 Common White
3 To RTI “Add Pump” Relay 24VAC Green
4 To Waste Solenoid - 3 Way 24VAC Brown
5
6 RTI JIB Valve Fill Solenoid
24VAC
Black
7 Ground - Fill Solenoid Black
J7 From RTI Box
8
From RTI "Waste Tank Full
Sensor" Test Pins 1 to 8
24VAC –
Full
0VAC –
Not Full Red
