Installation guide

8
DIAGNOSTICS - PARKING LIGHTS FLASH RATE
FLASHES RATE DESCRIPTION
1 Quick
Alarm system armed and doors locked or end of run time or run time canceled or trunk
open or canceled cold weather or cannot start after maximum attempts of tries
2 Quick Alarm disarmed and doors unlocked
3 Quick Entering Cold Weather Mode or Tach watch lockout
4 Quick The brake line went high and canceled cranking or run cycle
5 Quick New transmitter learned
6 Quick A remote start attempt was made with a tach or a vacuum signal detected
8 Quick Unit Reset: Occurs when the unit is reset to factory default
10 Quick The hood line went to ground during crank or run time
ON 4 sec.
The hood opened and the hood switch line went to ground. This is step one of the
programming modes.
ON 5 sec. The end stage of the procedure to program transmitters.
ON 20 sec.
If the hood switch is flashed (ground, open, ground), the unit went into step 1 of the
programming cycle and no transmitter activity was detected for 20 seconds.
ERRATIC -
If the unit flashes erratically (1 to 3 flashes, followed by a pause, then more flashes), it is
in playback mode. This occurs when the hood switch line is flashed twice (ground, open,
ground, open, ground).
CONSTANT
FLASHES
Up to 60
sec.
The unit is in an alarm condition either created by an intrusion, by the panic mode or
when the unit is powered-up.
HARNESS DESCRIPTION
HARNESS DESCRIPTION (5-PIN)
PIN # COLOR SIZE CONNECT TO
A
RED
(Battery)
14 AWG
Constant + 12V source (usually the largest wire) at key switch (30 AMP in-
line fuse must be added).
B
YELLOW
(Ignition)
14 AWG
Wire at key switch which has + 12V when key is in the Ignition (ON) and
crank (START) position.
C
VIOLET
(Starter)
14 AWG
Wire that has + 12V only when the key switch is in the crank Position.
(Attach a wire coming from pin 87A of the Starter kill relay if this feature is
used).
D
ORANGE
(Brake)
14 AWG
Wire at key switch that has + 12V when the Ignition key is in Ignition and/or
Accessories position only (not crank position).
E RED (Battery) 14 AWG
Constant + 12V source (usually the largest wire) at key switch (30 AMP in-
line fuse must be added).
