Installation guide

4
DISABLING ALARM VALET MODE
1. Make sure the Ignition key is in the OFF
position.
2. Set the alarm Valet switch to ON.
3. Turn Ignition ON and wait for 2 sec.
4. Set the alarm Valet switch to OFF. At this
point the LED turns and stays OFF to
indicate that the Alarm Valet Mode is disabled.
5. Turn Ignition OFF and put Valet switch to
OFF.
ENABLING STARTER VALET MODE
1. Make sure you did set the alarm valet mode, as
you require.
2. Set the Valet switch ON.
*Valet switch ON = Starter will not work
DISABLING STARTER VALET MODE
1. Make sure you did set the alarm valet mode, as
you require
2. Set the Valet switch OFF.
The remote starter is now in normal operation
TRANSMITTER FUNCTION
Once programmed, the transmitter will be
operational. (Hood must be closed)
The transmitter is depended on the module type.
*The STOP Button on AS-4565 has NO function.
NOTE: Pressing Lock, Unlock or Start button with
the vehicle running, parking brake engaged and the
doors closed, will put the unit into Ready Mode.
TACH ADJUSTMENTS
Autostart systems have two methods of fine-tuning
the tach signal that is generated from the vehicle,
the first method is manual tach search and setting,
and the second is automatic tach search and setting.
Either method can be used, however an automatic
search is recommended. Tach adjustment
procedures should be done every time a new
unit is installed. This is because the tach signal
from some Ignition systems can sometimes be too
high or too low, thus causing failed starts under
different temperatures.
The procedures for tach adjustment are as
follows:
1. Hold hood switch down for 4 seconds.
2. Release pinswitch (parking lights should come
ON)
3. With parking lights ON, immediately push and
release pinswitch again.
4. Parking lights will stay ON for up to 20
seconds (if not repeat from step 1)
5. With lights ON press TRUNK button of
remote transmitter at the same time.
(Parking lights will flash 1 to 7 times)
6. Start the vehicle using the key.
7. If Parking lights stays ON, then you have
selected an incorrect tach wire. (Relocate
tach wire and start from step 1) If lights go
OFF then proceed to the next step.
8. Allow vehicle to reach regular engine idle
speed, then press and release brakes.
(Parking lights will flash appropriate setting,
from 1 to 7 flashes)
9. Press TRUNK button of remote transmitter,
to save setting. (Parking lights will flash one
long flash)
NOTE: A manual adjustment should only be
done if the auto setting is not completing the
crank cycle properly in cold weather.
MANUAL TACH SEARCH AND SETTING
1. Hold hood switch down for 4 seconds.
2. Release pinswitch (parking lights should
come ON)
3. With parking lights ON, immediately push
and release pinswitch again.
4. Parking lights will stay ON for 20 sec. (if
not repeat from step 1)
5. Press TRUNK button of remote transmitter
at the same time (Parking lights will flash 1
to 7 times)
6. Now you can increase or decrease the tach
setting, depending on your needs.
7. LOCK button will decrease the setting, and
START button will increase the setting.
8. After proper setting has been reached, push
TRUNK button to save setting. (Parking
lights should flash once long)
CUSTOM PROGRAMMING OPTIONS
Autostart systems are equipped with 2 custom
programming menus that allow the user to
custom fit the system according to the
installation requirements.
These options are designed to help make
interfacing with all vehicles possible.
To get into custom programming mode you
must do the following:
1. Hold pin-switch down for 4 sec.
2. Release pins-witch (parking lights will come
ON)
3. Immediately push and release pins-
witch once again. (Parking lights will stay
ON for 20 sec.)
4. Press and hold brakes, and press 1 or 2 on
remote transmitter. (LOCK for mode one,
and START for mode two) Parking lights
