Installation guide

3
PROGRAMMABLE OPTIONS
• Door lock pulse duration ( 1 sec, 4 sec, or two
¼ sec unlock pulses).
• Programmable passive or active arming
• Silent Arming/disarming chirp control
• Programmable cold weather operation
• Ignition controlled door locks.
• Constant or pulsed Groundout when running.
• Run time (4,15, or 25 minutes)
• Maximum crank duration (6, 8, or 12 seconds).
• Gasoline or Diesel engine operation.
PROGRAMMING TRANSMITTERS
To use the transmitter with your alarm/starter
system, you must first have the system learn the
transmitter's code. The system can learn a total of
4 transmitters. If more than 4 transmitters are
programmed, the oldest codes will be replaced.
(The same transmitter can be coded 4 times to lock
out all other transmitters.)
NOTE: In order to program a new transmitter
code, Alarm Valet Mode must be disabled. Also,
when programming the transmitter, make sure that
no other transmitter is in use or the alarm/starter
unit may learn it.
1. Make sure that the Alarm Valet Mode is
disabled.(LED OFF)Valet switch in the OFF
position.
2. Turn the Ignition switch to ON.
3. Open the Hood
4. Turn the Valet switch ON, OFF, ON.
5. The parking lights will come ON. You have up
to 5 seconds to press LOCK button on the
transmitter to be added to the unit, if the
operation is successful, the alarm/starter unit
will flash the parking lights 5 times quickly.
Note that the Alarm Valet Mode is enabled at the
end of this procedure. You should disable it to
return to normal operation. If the unit could not
read the code, repeat the operation from step 1. If
you cannot program the unit after several tries,
there may be a problem with the transmitter or
remote starter unit.
MULTI CAR OPERATION (Only available on
AS-4563/ 4564 / 4565 & 4574)
*To program transmitter to second vehicle for
multi-car operation, you must press on the
transmitters TRUNK button in step 5 of
transmitter code learning.
(See above for Transmitter code learning)
The AS-4563/4564/4565/4574 systems feature
Multi-car operation.
This allows the owner of two Autostart systems
in two of his/her vehicles to control both systems
with one transmitter. (Both vehicles must be
equipped with an AS-4563/4564/4565/4574.
The remote transmitter of the primary vehicle
can control the starter disable system, the door
locks and the remote car starter operation of the
second vehicle. The remote transmitter of the
second vehicle can also operate the primary
vehicle
REMOTE STARTER & ALARM VALET
MODES
The alarm / starter unit can be placed in Remote
Starter Valet Mode to disable the capability of
starting the engine by the unit while maintai-
ning the alarm, door locking/unlocking functions
and trunk. This is recommended if the vehicle is
to be parked in a garage or if the vehicle needs to
be serviced.
The alarm / starter unit can also be switched to
Alarm Valet Mode to stop an alarm condition or
to disable the alarm functions and the anti-theft
starter kill feature. While in the Alarm Valet
Mode, the remote starting capability, the panic
mode, door locking / unlocking functions and
trunk are still operational.
NOTE: Enabling Alarm Valet Mode is required
if you want to stop the initial alarm condition
that occurs when powering-up the system.
Using one of the next options will permit the
user to place the alarm/starter in any one of the
following combinations using the single Valet
switch:
• Normal operation
• Alarm valet mode only
• Starter valet mode only
• Alarm and starter valet modes
ENABLING ALARM VALET MODE
1. Make sure the Ignition key is in the OFF
position.
2. Set the Valet switch to OFF.
3. Turn Ignition ON and wait for 2 sec .
4. Set the Valet switch to ON. At this point the
LED turns and stays ON to indicate that
the Alarm Valet Mode is enabled.
5. Turn Ignition OFF and then put Valet switch
back to OFF.
