What’s included……………………….……..2

Install points to remember…………………..2

Features……………………………………….2

Options………………………………………..2

Programmable Features….…………………3

Programming transmitter.………...………..3

Multi-Car Operation……………………...…3

Remote starter & alarm Valet Modes..…….3

Transmitter function.………………..….…..4

Tach Adjustment……….………………..….4

Custom Programming Options…..….…….5

Tach watch Lockout………………………...5

Diesel Engine.…………………….……………6

Getting into Ready-Mode……………………..6

Staying in Ready-Mode……………………….6

Clutch bypass………………………………..…6

Parking Brake Wire………………………...….6

Programmable 5

relay………………………..7

Module Reset…………..……………….………7

Problem & Solutions…………………………..7

Parking light flash diagnostics…………..…...8

Harness Description………………..….…..….8

Wiring Schematic………….…..…….….……10

AUTOSTART

AS-4560/4563/4564/4565/4574 - SH

Manual

transmission remote starter & full-featured alarm system.

NOTICE:

DUE TO THE POTENTIAL FOR DAMAGE TO THE VEHICLE, THE MANUFACTURER IS

NOT RESPONSIBLE FOR ANY ELECTRICAL DAMAGE TO THE VEHICLE OR TO THE

UNIT THAT HAS CAUSED VEHICLE DAMAGE DUE TO IMPROPER INSTALLATION OF

THE PRODUCT.

THIS UNIT MUST BE INSTALLED BY AN AUTHORIZED AUTOSTART TRAINED

TECHNICIAN USING ALL SAFETY DEVICES SUPPLIED.

Please review the installation guide carefully before any work begins.

WARNING

THIS UNIT IS FOR MANUAL TRANSMISSION ONLY, BEFORE INSTALLING THE UNIT

TEST THAT THE VEHICLES OEM DOOR SWITCH CONTACTS WORK WELL, AND

THAT THE PARKING BRAKE SYSTEM OPERATES PROPERLLY.

DO NOT INSTALL ON CONVERTIBLE VEHICLES UNLESS A RADAR SENSOR IS USED

TO DETECT MOTION IN THE VEHICLE.

Rev: 2.10 La

–

11/30/01 Manufactured in Canada b

AUTOSTART

INSTALLATION GUIDE

Table of Contents

Summary of content (10 pages)

PAGE 1
AUTOSTART AS-4560/4563/4564/4565/4574 - SH Manual transmission remote starter & full-featured alarm system. INSTALLATION GUIDE Table of Contents What’s included……………………….……..2 Diesel Engine.…………………….……………6 Install points to remember…………………..2 Getting into Ready-Mode……………………..6 Features……………………………………….2 Staying in Ready-Mode……………………….6 Options………………………………………..2 Clutch bypass………………………………..…6 Programmable Features….…………………3 Parking Brake Wire………………………...….6 Programming transmitter.………...………..
PAGE 2
WHAT’S INCLUDED FEATURES Please review the installation guide before beginning the installation, particularly the wiring diagram and the list of programming options. Prior to installation please be sure that all hardware components required to install the system are in the box. The following is a list of components included in the Kit: • 1 – Control unit • 2 – Transmitters (Depends on model) • Plug-in shock dual zone shock sensor • Plug-in ultra bright L.E.
PAGE 3
The AS-4563/4564/4565/4574 systems feature Multi-car operation. This allows the owner of two Autostart systems in two of his/her vehicles to control both systems with one transmitter. (Both vehicles must be equipped with an AS-4563/4564/4565/4574. The remote transmitter of the primary vehicle can control the starter disable system, the door locks and the remote car starter operation of the second vehicle.
PAGE 4
5. DISABLING ALARM VALET MODE 1. 2. 3. 4. 5. Make sure the Ignition key is in the OFF position. Set the alarm Valet switch to ON. Turn Ignition ON and wait for 2 sec. Set the alarm Valet switch to OFF. At this point the LED turns and stays OFF to indicate that the Alarm Valet Mode is disabled. Turn Ignition OFF and put Valet switch to OFF. 6. 7. 8. 9. ENABLING STARTER VALET MODE 1. Make sure you did set the alarm valet mode, as you require. 2. Set the Valet switch ON.
PAGE 5
hood switch. The programming of these four functions (and those from Mode 2) will play back in sequence via the parking lights. will flash once for mode 1 and twice for mode 2. After you have entered into one of the two programming menus you can release the brake pedal. The unit will stay in programming mode until the hood pinswitch is pressed or the Valet switch has been turned OFF.
PAGE 6
NOTE: If module is still in Tach Watch Lockout move tach wire to a better tach source and perform an Automatic Tach Setting. Repeat steps 1 to 5. Most manual transmission vehicles will require the clutch to be pressed in order for the vehicle to crank. This being true under remote start as well, so a clutch bypass must be performed.
PAGE 7
The systems are equipped with a reset function that allows the installer to erase all transmitter codes and return all programmed options to factory default. Make sure Alarm Valet Mode is OFF. To reset the module: 1. Open a door. 2. Raise the Hood. 3. Turn the Ignition “ON”. 4. Press and hold brakes. 5. Turn Valet switch ON, OFF, ON, OFF, ON, OFF, ON, OFF. (Switsh must go to ground at least 4 times) 6. Parking lights should flash 8 times quickly.
PAGE 8
DIAGNOSTICS - PARKING LIGHTS FLASH RATE FLASHES RATE 1 Quick 2 3 4 5 6 8 10 Quick Quick Quick Quick Quick Quick Quick ON 4 sec. ON 5 sec. ON 20 sec. ERRATIC - CONSTANT FLASHES Up to 60 sec.
PAGE 9
HARNESS DESCRIPTION (7-PIN) PIN # 1 COLOR Black (Ground) SIZE 18 AWG 2 Violet (Tach or Vacuum) 18 AWG 3 Grey (Hood) 18 AWG 4 White (Ground out) 18 AWG 5 Orange (Brake) 18 AWG 6 Green Yellow (Parking lights) 18 AWG 7 18 AWG CONNECT TO Good solid ground, usually on the metal frame of the vehicle Negative (-) side of coil or tach wire of electronic distributor.
PAGE 10
AS-4560 /4563 /4564 /4565 SH WIRING DESCRIPTION ANTENNA SIREN NON FLASHING L.E.D Plug-In Shock Sensor ALARM VALET SWITCH (Blue) 21 - . . . . . . . . . . . . . . . . . . . . . L.E.D. / +12V. 7 - YELLOW . . . . . . . . . . . . . Parking lights (+) 6 - GREEN . . . . . . . . . . . . . . Data-out. 5 - ORANGE . . . . . . . . . . . . Brake Lights (+) 4 - WHITE . . . . . . . . . . . . . . . Ground-out. 3 - GREY . . . . . . . . . . . . . . . . Hood switch 2 - VIOLET . . . . . . . . . . . . . .
