WINCUEPRO FOR AVSTAR USER GUIDE APPENDIX A
VERSION 1.30 89  QTV 2001
Appendix A The IMT Card
In the following appendix we will look at the entire configuration options available for
the IMT board.
Card Layout A2
Termination - J6 A3
Power to Bus for SCSI Termination - J6 A3
SCSI ID – SW2 A4
SCSI/Parallel Select - SW2 A4
Video (PAL or NTSC) - J11 A5
SECAM A5
External Power Supply - J12 A6
Composite Video Features Connector - J10 A6
Other Jumpers A6
The IMT card is configured at the factory to work in your country. It is unlikely that you
will need to make any changes to it. If you do, read the relevant section(s) carefully, or
consult your supplier for further help before changing the configuration of the board.
A2 Card Layout
The following section shows the 3 IMT card layouts that have been produced over the
years, most recent of which being the Issue 3 I.M.T card. You will have been supplied
with one of the 3 IMT cards, use the diagrams below to help you locate all the
connectors and jumpers on the card that you have been supplied with.
