11
2) Operating Temperature: 0°C to 60°C (32°F to 140°F)
3) Storage Temperature: -20°C to 70°C (-4°F to 158°F)
4) External Power: 8.0 to 18.0 V power provided via vehicle battery
5) Dimensions:
Length Width Height
199 mm (7.83”) 104.5 mm (4.11”) 37.5 mm (1.48”)
6) Weight: 280 g (without wire) 484 g (with wire)
Accessories Included
1) User Manual – instructions on tool operations.
2) OBD II Cable – used to connect tool to vehicle for communication and
to power tool.
3) USB Cable – used to connect to Windows PC for printing data saved
on tool and to update the tool’s software.
4) Quick Guide – instructions on registering tool and updating software.
Navigation Characters
Characters used to help navigate the scan tool are:
1) $ – identifies the control module number from which data is retrieved.
Indicates the Test ID in On-Board Monitor Test.
2) ? – indicates help or DTC Guide information is available.
3) G – indicates graphic viewing is available.
Keyboard
No solvents such as alcohol are allowed to clean the keypad or display. Use
a mild nonabrasive detergent and a soft cotton cloth. Do not soak the
keypad as the keypad is not waterproof.
