Users Manual
Table Of Contents

distance between Base station and ground station: 200m
(no interference, no obstruction; the height of
the base station is 2m from the antenna to the
end of the tripod, and the height difference with
the remote control is within 10m, on the ground
The
height of the station above the ground is
0.2 m)
Memory capacity No
inertial
measurem
ent unit
Functional
characteristics
Built-in 6-axis IMU
electrical
characteris
tics
Power
consumption
7.5 W
Power supply 5 to 20 VDC
Battery type: Lithium polymer battery
Capacity: 4950 mAh
Energy: 57.1 WH
Working time > 7.5 h
Physical
characteris
tics and
dimensions (base
station body +
extension pole)
193 mm×177 mm×73 mm
Weight 1275g
Dust-
proof and
waterproof
IP56
Working
environme
nt
temperatu
re
-20℃ to 50℃
