Manual

39
3) Press the ESC button to return to previous menu.
Viewing Custom Data Set
1) To view customized PID data, use the UP/DOWN scroll button
to select Custom Data Set from View Data menu and press the
OK button. (Figure 5.13)
2) Observe on-screen instructions.
Figure 5.16
3) Use the RIGHT button to deselect/select data parameters, and
use the UP/DOWN scroll button to move up and down. Selected
parameters are marked with solid squares.
Figure 5.17
 The number “x” to the upper right corner of the screen
indicates sequence of highlighted item; and “#x” are the order
that the parameters are selected and will be displayed.
…………..Custom Data Set 4/26
 DTC_CNT
 FUELSYS1
 FUELSYS2 ?
 LOAD_PCT #01
 ECT
 SHRTFT1
……………Custom Data Set……… …..
[
] – Select/Deselect
[
] – Deselect all
[OK] – Confirm
[ESC] – Cancel
Press any key to continue.
