User Manual

INTRODUCTION
Thank you for your purchase of ‘Wireless Handle Air Pump’ - the hand-
held air pump that makes it easy and quick to inflate car tires and more.
It also has an auto-stop feature that will stop at your desired tire pressure
automatically and additional nozzle attachments for a variety of uses.
The product is suitable for automobiles, motorcycles, bicycles, electric
cars and ball, small inflatable toys,air. The ‘Wireless Handle Air Pump’ can
also serve as a tire pressure gauge. Please be sure to read, understand,
and strictly follow all instructions before use.
Also, keep the manual properly for future reference.
Product Part List
Shell
Hose port
LED light
Battery Pack Button
Digital display
Charging port
Lithium Battery pack
Air hose
Lithium battery base
USB charging line
Balloon PIN
Balls Pin
Start button
Cigarette lighter plug
(No battery version)
Pack List:
1 × Tire Inflator
1 × Lithium Battery Base
1 × Cigarette lighter plug base(No battery version)
2 × Air Hose
1 × Gift Box
1 × Portable Zipper Bag
1 × User Manual
1 × USB Charging Cord
2 × Tapered Nozzle
1 × Inflatable Nozzle
4 × Tire Caps
1 × Presta Valve Adaptor
Technical Parameters
Product model: FC-368
Product name: Wireless digital display air pump
Input voltage: dc 12.6v/1000Ma
Operating voltage: dc 10.8v
Maximum current: <9A
Battery capacity: 2600Ma
Inflation efficiency: 165/60r14 0—2.5kg/CM2
Squared within 4 minutes
LED: 8LM
Maximum atmospheric flow: 35L/min
Maximum inflation pressure:120PSI
Pressure units: PSI, BAR, kPa, KG/CM2
Length of external pipe: 180mm±10mm
Length of power cord (no battery package): 4m±10mm
Ambient temperature: -20C-50C/-4F-122F
Remove the battery from the ‘Wireless Handle Air Pump’ by
pressing battery pack button in and pulling out
Plug the USB charger into a USB port. Then, connect to the USB
charger port on the battery
When LED light on the charger changes from red to blue,
the battery is charging.
Takes 3-5hours to full-charged status.
Ensure that the exterior of the ‘Wireless Handle Air Pump’ is clean
and dry before connecting the charger.
Insert the battery into the appliance (‘Wireless Handle Air Pump’)
base, and push the battery until it’s securely latched in.
Press the battery pack button before removing the battery,
and disengage the battery from the ‘Wireless Handle Air Pump’ base.
Switch ‘Wireless Handle Air Pump’ on by pressing the start button.
When you release the start button, the Inflator will be immediately
switched off.
When using the ‘Wireless Handle Air Pump’ outdoors, make sure
that no sand enters the ventilation grill.
Make sure that the ‘Wireless Handle Air Pump’ is appropriately
connected to the item being inflated and use only provided air hose
and pins.
Always check the maximum pressure of item before inflating.
1.Children are not allowed to use this air pump! Keep out of reach of
children!
2.Never insert the windpipe into the mouth, ears, and eyes of a person
or animal. Don't use the pump as a toy.
3.It is prohibited to use the pump in the flammable and explosive liquids
and gases area (such as gas stations)
4.High-pressure gas will generate heat during inflation. To ensure the
excellent operation of the air pump, after each continuous operation
for 15 minutes, the machine must be stopped for 15-20 minutes to cool
down so that it can be used to ensure the service life of the air pump.
5.In case of abnormal noise or excessive temperature during inflation,
please shut down the machine immediately and allow it to cool down
for at least 15 minutes.
6.The connector may be hot. Use caution when removing it.
7.When using this product, you should avoid rain, dropping, or striking
down.
8.If stored for a long time, it is recommended to charge every six months.
9.Make sure the air pump is fully charged before use.
10.Please charge the inflator only with the attached charger/cable
components.
CHARGING THE BATTERY PACK
CONNECTING AND REMOVING THE BATTERY
SWITCHING ON AND OFF
DURING USE
USING THE CIGARETTE LIGHTER ADAPTER PACK
Unravel cord before use.
If the lithium battery pack is already attached, remove from ‘Wireless
Handle Air Pump’ by pressing locking tabs in and pulling out
Slide the cigarette lighter Adapter pack into ‘Wireless Handle Air Pump’
until you hear a click
Connect the cigarette lighter adapter plug into the cigarette socket in
your car
When ready to use, power car on. Always operate vehicle outdoors.
INFLATION INSTRUCTIONS
Screw the air hose with threaded connector into the hose port. Press
in firmly and screw clockwise until it can not go further.
Tighten attachment lock clockwise until hand-tight.
Press the Power button (M) below the LCD to turn on.
To select preferred pressure format PSI, BAR, kPa, KG/CM2, press
the power button (M) continuously until desired format displays.
Insert the air hose connector onto tire’s valve stem. The gauge will
show current tire pressure when connected.
Press “+” or”-” to set the desired pressure level. Once the pressure
level has been set, wait a few seconds and until current tire pressure
displays.
Make sure the air hose trigger lock is in unlock position, then press
the trigger.
‘Wireless Handle Air Pump’ will begin to inflate the tire. The device
will stop automatically when the set pressure level is reached.
When done, press the air hose trigger once to turn off, and slide trigger
lock to lock position.
Remove the air hose trigger from the tire, and replace valve stem cap
on the tire, if required.
Memory function
The Initial preset value of the inflator is 36PSI.
Please kindly note that if the preset value is （like）50PSI, and it
reaches 50 PSI while using, then next time the preset value will be the
same as last time you have set it.
INFLATING ITEMS WITH ADDITIONAL NOZZLE
Insert the air hose into the hose port. Press in firmly and screw clockwise
until it can not go further.
Attach the additional nozzle to the air hose trigger.
Press the Power button (M) below the LCD to turn on.
Insert the nozzle adapter into an inflatable object and push the trigger.
Allow ‘Wireless Handle Air Pump’ to run until fully inflated.
Remove nozzle adapter from the inflated object, and replace valve cover
if required.
MAINTENANCE
The ‘Wireless Handle Air Pump’ is designed to function with minimum
maintenance and without difficulty for a long time. Life span may be pro-
longed by following all use and safety instructions and regular cleaning.
CLEANING
Clean the casing frequently, with a soft cloth after each use.
SAFETY CAUTIONS
6 7
Wireless Portable Air Compressor
