QA-FR-175-A

User’s Guide

November 2020

Revision 1.0

ARI UNI42 60GHz Radar Module

1. Introduction

The UNI42 radar module from Augmented Radar Imaging is an easy-to-use board that contains 60-GHz

mmWave Radar transceiver with patch antennas etched on PCB and acts as a Radar front-end module. It can

be used in various applications where object detection, distance measurement, or speed measurement are

required. The radar module is equipped with 12-pin and 32-pin connectors to interface external peripherals and

host boards so that the users can customize for their specific applications.

2. Hardware Features

2.1. Features

 Radar tuning frequency: 60-64GHz

 Number of Receivers: 4

 Number of Transmitter: 3

 Processing: MCU, FFT accelerator, DSP

 Memory: 1.75 MB

 Antenna: microstrip patch antenna

 Onboard temperature sensor

2.2. Interface Connectors

There are two connectors on the UNI42 Radar module. They are used as interface to the host

system and/or peripherals. The pins include power rails, SPI interface, I2C bus, and other

miscellaneous signals.

Pin Number

Description

Pin Number

Description

3V3

DRV_INT_L

GND

I2C_SCL

I2C_SDA

RESET_L

SPI_CS_L

SPI_CLK

SPI_MISO

SPI_MOSI

GND

Table 1: J1 12-pin Connector Pinout

Summary of content (5 pages)

PAGE 1
User’s Guide November 2020 Revision 1.0 ARI UNI42 60GHz Radar Module 1. Introduction The UNI42 radar module from Augmented Radar Imaging is an easy-to-use board that contains 60-GHz mmWave Radar transceiver with patch antennas etched on PCB and acts as a Radar front-end module. It can be used in various applications where object detection, distance measurement, or speed measurement are required.
PAGE 2
Pin Number 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 Description Pin Number 3V3 2 I2C_SDA 4 I2C_SCL 6 SPI_CS_L 8 GND 10 RESET_L 12 PWR_DWN_L 14 DRV_INT_L 16 3V3 18 RADAR_NRST 20 RXD4 22 NC 24 NC 26 NC 28 SPI_MISO 30 SPI_MOSI 32 Table 2: J2 32-pin Connector Pinout Description 5V 5V GND TXD0 RXD0 FAN_CTRL GND SOP2 EN_3V GND RADAR_GPIO_0 NC SPI_CLK NC NC NC 2.3. Onboard Antenna The UNI42 Radar module has built-in microstrip patch antennas for both transmitters and receivers.
PAGE 3
4. Regulatory Compliance 4.1. Operational Considerations TheUNI42 Radar module is designed to transmit at power level that meets the FCC EIRP peak power requirement. The host manufacturer does not have the ability to adjust the output power. 4.2. RF Exposure Considerations In accordance to the EN 62311 RF exposure test on the Radar transceiver, a minimum separation distance of 20 centimeters should be maintained between the user and the UNI42 Radar module during operation.
PAGE 4
IC ES-003 compliance through testing with the UNI42 module installed. 4.5. FCC Statements per 47 CFR §15.105 Class B Device Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
PAGE 5
OEM Warnings The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC/ISED identification number: (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC/ISED identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring
