Technical data

80 COMpact 3000 analog/ISDN/VoIP - Firmware Version 4.0 - Version of the Manual 03 02/11
Using the Configuration Manager
Configuration Manager
Operating Instructions for the Configuration Manager
2. Enter the IP address of the PBX in the address field of the browser (for example,
http://192.168.178.4).
3. Under User name, enter the sub-admin user name.
4. Under PIN, enter the admin PIN.
5. Click Log-in.
The configuration manager opens.
Further steps:
– Configure the desired settings in sequence (page for page).
Operating Instructions for the Configuration Manager
The operating instructions for the configuration manager contain the following topics:
• Navigation
• Logging Out
• Entry and Selection Fields
• Creating and Deleting Table Entries
• Symbols and Highlightings
• Display/Legibility
Configuration Manager Navigation
In the configuration manager, the main topics are listed in the horizontal navigation bar (main
navigation). These are recognizable because they are written with capital letters.
The sub-topics of the main topics are listed in the vertical navigation bar to the left in the confi-
guration manager. Depending on the main topic you click, the associated sub-topics are
displayed under Navigation.
After clicking a sub-topic under Navigation, the page for the corresponding sub-topic opens.
There are different topic areas listed that can be opened most of the time. Click to open the
corresponding topic areas. Click to close the open topic areas. On some pages, the topic
areas themselves also have sub-topics that can be opened. Click to open the sub-topics of
the topic areas, and click to close them again.
Using the list field at the bottom to the left in the configuration manager, various overview
lists can be opened. Select the overview list you want from the list field and click .
