64 COMpact 3000 analog/ISDN/VoIP - Firmware Version 4.0 - Version of the Manual 03 02/11
Installing and Switching on the PBX
ISDN End Devices
Connecting the Cable and the Wall Sockets to the Internal U
P0
Port
Connecting the Cable and the Wall Sockets to the Internal U
P0
Port
Requirements:
– Cover panel is removed
– Internal U
P0
port (only provided at the optionally available COMpact ISDN module)
– Terminators enabled at the internal U
P0
port
– Installation cable (z. B. J-Y(St)Y 2x2x0,6)
– Under unfavorable conditions, for example, near a strong transmitter or an electrical power
line: screened cable
– ISDN wall sockets (e. g. IAE or UAE8)
– Compliance with the maximum distance/line length between the devices, depending on the
cable used (with a pair diameter of 0.6 mm: unscreened max. 1000 m, screened max. 600 m)
–U
P0
/S
0
adapter
Note:
For connecting one single COMfortel 1100/1500/2500/2500 AB system
telephone, a U
P0
/S
0
adapter is not necessary.
You do not need an ISDN wall socket if you use a U
P0
/S
0
adapter. The U
P0
/
S
0
adapter can be mounted on the wall or it can be connected to the PBX
via the two screw terminals on the back.
Warning: Power surges, which can occur during electrical storms, can
cause life-threatening electric shocks or damage/destroy the PBX.
• Lay all the cables inside the building.
Caution: Terminals integrated in the wall sockets are destroyed and can
damage the device.
• In comparison with the S
0
port, do not equip a line end at the U
P0
port
with terminals. These are already integrated in the end devices
(COMfortel 1100/1500/2500/2500 AB or U
P0
/S
0
adapter).
• Remove terminals which have already been integrated in the wall sockets
for the usage at the U
P0
port.
