14. Enter a filename with the ending .cf2 and click Save (this text is dependent on the
operating system used).
15. Open the menu File > Save.
16. Click Telephone.
The Connection routes dialog opens with the devices connected via the configured
interface.
17. Select the telephone on which you would like to save the configuration and click OK.
The PIN entry dialog opens.
18. Enter the associated PIN in the PIN entry field and click OK.
The configuration is saved on the telephone. This may take a while.
Configuring ISDN System Telephones Remotely via the External S
0
Port on the
PBX (Externally)
Important: Before you can configure the system telephones remotely, the
required configurations must first be made via an internal network connection
on the PBX.
Requirements:
– External S
0
port (only COMpact 3000 ISDN or COMpact ISDN module available as an
option)
– Configured remote switching number for system telephones
Note: If no remote switching number for system telephones has been confi-
gured, the PBX must be activated for remote configuration using a digit
sequence on an internal telephone. After this, the PBX is accessible over
each associated MSN/DDI.
– Configured dealer access number
Note: If no dealer access number has been configured or the telephone
number transmitted does not correspond with the configured telephone
numbers, the PBX must be activated via an internal telephone using a digit
sequence for remote configuration.
