346 COMpact 3000 analog/ISDN/VoIP - Firmware Version 4.0 - Version of the Manual 03 02/11

Configuring and Managing the PBX

Internet Access

Configuring the HTTP Proxy

An HTTP proxy is a proxy for the HTTP protocol, over which Internet sites are called or files

downloaded.

The configuration can be made as follows:

• Via the configuration manager

Requirements:

– Configuration manager, opened with sufficient authorization

– Expert view (click )

1. Open the page CONFIGURATION > Server configuration > Network.

2. Select or clear the HTTP proxy check box under HTTP proxy configuration.

3. In the IP address or URL entry field under HTTP proxy configuration, enter the

HTTP proxy. The following entries are possible:

4. In the Port entry field under HTTP proxy configuration, enter the associated port

number (port). The following entries are possible:

5. Select or clear the Proxy authorization check box under HTTP proxy configu-

ration.

6. Enter the user name for the authorization into the HTTP proxy in the User name entry

field under HTTP proxy configuration.

7. Enter the password for the authorization into the HTTP proxy in the Password entry

field under HTTP proxy configuration.

Further steps:

– Save your settings before you leave the page.

Enables the HTTP proxy.

Disables the HTTP proxy. (No other action is required.)

IP address with a range of 0 to 255 (example: 123.123.123.123)

URL (example: www.proxyserver.de)

1 to 65535

Enables proxy authorization.

Disables proxy authorization. (No other action is required.)
