Configuring and Managing the PBX
Identification
Configuring the Gateway
Configuring the Subnet Mask via an Internal Telephone
Requirements:
– Disabled DHCP client
– Knowledge of the sub-admin or admin PIN
1. Pick up the receiver.
2. Dial ##8.
3. Enter the sub-admin or admin PIN.
4. Dial *932*.
5. Enter the IP address of the subnet mask. The following entries are possible:
6. Dial #.
7. Hang up the receiver.
Querying the Subnet Mask via an Internal Telephone
Requirements:
– CLIP-enabled telephone
– CLIP function enabled in the PBX (display of the telephone numbers)
1. Pick up the receiver.
2. Dial ##8*942#.
3. Hang up the receiver.
You will get a call. The subnet mask is shown on the telephone display.
Configuring the Gateway
The Gateway can be configured as follows:
• Via the configuration manager
• Using a character string on the internal telephone
12 digits (e.g.: for the IP address 255.255.255.0, enter 255255255000)
