Technical data

COMpact 3000 analog/ISDN/VoIP - Firmware Version 4.0 - Version of the Manual 03 02/11 255
Configuring and Operating Functions
LCR
Switching LCR on the External Connection On/Off
4. Make sure you have current LCR data:
• Import data (Soft LCR 4.0)
• Enter data manually (Soft LCR 4.0):
5. Create the holidays in the calendar on the PBX and enable them for LCR.
Switching LCR on the External Connection On/Off
If LCR is enabled on the external connection, the external port is used for LCR calls.
Note: Manual LCR by dialling a preceding provider area code is always
possible if the network provider supports call-by-call.
Switching this on/off can be done as follows:
• Via the configuration manager
Requirements:
– External analog port (only on the COMpact 3000 analog) or external S
0
port (only
COMpact 3000 ISDN or COMpact ISDN module available as an option)
– Configuration manager, opened with sufficient authorization
– Expert view (click )
– Configured prefixes (country prefix and local area code)
1. Open the page CONFIGURATION > External numbers.
2. In the list field at the top, select the connection in question.
A page opens for configuring the connection in question.
3. Open one of the following pages:
• Analogue connection > Name and functions
• ISDN connection > Name and functions
LCR providers
Tariff groups (LCR networks and the corresponding LCR prefixes)
Tariff information (LCR tables)
