Technical data

248 COMpact 3000 analog/ISDN/VoIP - Firmware Version 4.0 - Version of the Manual 03 02/11
Configuring and Operating Functions
LAN-TAPI
Configuring the Network Port on the TAPI Server
Requirements:
– Configuration manager, opened with sufficient authorization
– Expert view (click )
1. Open the page FUNCTIONS > LAN TAPI > LAN TAPI subscribers.
2. Select or clear the check box next to the corresponding subscriber.
Further steps:
– Save your settings before you leave the page.
Configuring the Network Port on the TAPI Server
According to the factory settings, the network port on the TAPI server is pre-defined at 7001 by
default.
The configuration can be made as follows:
• Via the configuration manager
Requirements:
– Configuration manager, opened with sufficient authorization
– Expert view (click )
1. Open the page FUNCTIONS > LAN TAPI > LAN TAPI configuration.
2. In the Network port (1024-65535) under TAPI server entry field, enter the port
number on the TAPI server. The following entries are possible:
Further steps:
– Save your settings before you leave the page.
Configuring the Password for the Network Connection on the TAPI Server
The configuration can be made as follows:
• Via the configuration manager
Selects the subscriber for LAN-TAPI.
Clears the subscriber for LAN-TAPI.
1024 to 65535
