Technical data

24 COMpact 3000 analog/ISDN/VoIP - Firmware Version 4.0 - Version of the Manual 03 02/11
Important Information
Intended Use
• Analog telephone with pulse dialling
Important: Devices using pulse dialling cannot use the full range of features.
• Analog fax machine
• Analog answering machine
• Modem
• a/b door terminal system, e. g. TFS-Dialog 200/300, TFS-Universal a/b
Internal S
0
Port (only provided at the optionally available modules COMpact S
0
module
and COMpact ISDN module)
An internal S
0
port is suitable for connecting one of the following terminal devices:
• COMfortel 1100/1500/2500/2500 AB system telephone (as of firmware version 4.0B)
• COMfortel DECT 900/900C system telephone
• ISDN telephone in compliance with the Euro ISDN Standard (DSS1)
• ISDN PC controller in compliance with the Euro ISDN Standard (DSS1)
Important: The power consumption of the end devices on an S
0
port may
total a maximum of 2.5 W.
Internal U
P0
Port (only provided at the optionally available COMpact ISDN module)
An internal U
P0
port is suitable for connecting one of the following terminal devices:
• COMfortel 1100/1500/2500/2500 AB system telephone (as of firmware version 4.0B)
All other devices can only be connected to the U
P0
port via a U
P0
/S
0
adapter. It provides a S
0
port with two Western sockets by converting 2-wire to 4-wire. It is suitable for connecting the
following terminal devices:
• COMfortel DECT 900/900C system telephone
• ISDN telephone in compliance with the Euro ISDN Standard (DSS1)
• ISDN PC controller in compliance with the Euro ISDN Standard (DSS1)
Important: The power consumption of the end devices on a U
P0
port may
total a maximum of 2.5 W.
