USER'S MANUAL
AD LINK-OUT
5.7.1. OUTPUT TO AN AMPLIFIERS SYSTEM PROVIDED WITH AD LINK
AND AC LINK CONNECTION (THESIS TH / AV AMPLIFIERS)
(see section 7.2.2.12 - 7.2.3.9 - 7.2.4.5)
Remark: the output channels are 13
in total. The sum of the channels of
the ampliers connected must not
exceed 13. To increase the number of
channels, however, the same function
(AMP ID) can be assigned to more
than one amplier.
CH A: 1-2
CH A: 1-2
AD LINK 1
AD LINK 2
CH A: 5-6
CH C: 5
CH B: 3-4
CH B: 3-4
CH B: 7-8
WARNING: Output setups, with speakers named: Surround
Left/Right, Front Super Tweeter Left/Right, Front
MiD Bass Left/Right, Rear Midrange, are not
compatible with AV bit In digital inputs. The same
Setups are incompatible with AUTO SET systems
performed with bit Tune.
5.7 OUTPUT SIGNALS
4
ON TH
OVL SPK
AV bit IN
LEVEL S
(0.3 - 5V)
CH A
AV quattro
15
2
3
4
CH B
15
2
3
4
MENU DOWN ENTE RUP
AV bit IN
REAR
FRONT
LEVEL S
(0.3 - 5V)
CH A
ON TH
OVLS PK
AV 5.1k
15
2
3
4
CH B
15
2
3
4
CH C
15
2
3
4
MENU DOWN ENTE RUP
4
ON TH
OVL SPK
AV bit IN
LEVELS
(0.3 - 5V)
CH A
AV quattro
15
2
3
4
CH B
15
2
3
4
MENU DOWN ENTE RUP
CH1÷CH8 CH9÷CH13
bit One HD Virtuoso
Top Side
