MMD11 A 11" OVERHEAD LCD MONITOR WITH DVD PLAYER OPERATION MANUAL 128-8652
Important Notice Installation of overhead products requires careful planning and preparation. Be extremely careful when working on a vehicle with side curtain air bags. Do not route wires near any portion of the side curtain air bag assemblies. This includes any anchor points in A, B, C or D pillars of the vehicle. Routing wires in these areas or running wires by the side curtain air bags can prevent the side curtain air bag from fully deploying which can result in personal injury to vehicle occupants.
Congratulations Congratulations on your purchase of the Movies 2 Go MMD11 A DVD Player with Drop-Down Video / Monitor. The MMD11 A has been designed to give you and your family many years of video entertainment in the mobile environment. Please read the directions that follow to familiarize yourself with the product to ensure that you obtain the best results from your equipment.
CONTROLS AND INDICATORS DIAGRAM (FRONT VIEW) 8 76 5 43 2 1 9 10 11 12 13 14 15 16 1. EJECT () Button This Button is used for ejecting discs from the disc Compartment when the source is DVD and the unit is powered up. 2. STOP (n) Button This button is used to stop playback. 3. Source Select Use to select one of the four sources: DVD, AUX,AV1. 4. Picture Select (+) To increase the level of selected picture controls. 5. Picture Select Button Allows the user to enter the picture adjustment mode.
6. Picture Select (–) To decrease the level of selected picture controls. 7. FMM Source Select Switch Used to select the frequency in sequence rotation: FM OFF, CH1 88.1MHz, CH2 88.3MHz, CH3 88.5MHz, CH4 88.7MHz, CH5 88.9MHz, CH6 89.1MHz, CH7 89.3MHz, CH8 89.5MHz, CH9 89.7MHz, CH10 89.9MHz, CH11 90.1MHz, CH12 90.3MHz, CH13 90.5MHz, CH14 90.7MHz, CH15 90.9MHz, CH16 91.1Mhz. 8. PLAY (u) Button This button is used to start playback of a disc. 9. POWER ( ) Button Used to turn the system on/off. 10.
CONTROL FUNCTION DESCRIPTION (SIDE VIEW & BACK VIEW) Side View 1 1. DVD Disc insertion Slot For loading and removing discs. Unit must be in a powered on state to load disc when disc is inserted. Insert disc with label side facing up. Back View 1 2 3 1. Auxiliary Video Input 2. Auxiliary Audio Left Input 3. Auxiliary Audio Right Input REMOTE CONTROL OPERATION Battery Installation Before attempting to operate your Remote Control, install the batteries as described below.
MAIN FUNCTION DESCRIPTION 1 2 3 4 5 POWER MONITOR SELECT EJECT 35 M1 M2 TV DVD 1 2 3 4 5 6 7 8 SOURCE AUTO MEMORY 6 34 SKIP/ SEARCH 7 ERASE/ WRITE 8 9 10 11 12 13 0 CHANNEL FMM ON/OFF SELECT DAY/ NIGHT PIX RETURN DISPLAY IRT ON/OFF MUTE 33 32 31 30 29 OK 14 15 9 VOLUME MENU SETUP 28 16 17 18 AUDIO SUBTITLE REPEAT ZOOM A-B 19 20 21 22 23 27 26 25 24 * Function control is available on the unit and the remote control. ** Function not available in this model. 1.
4. DVD Mode Select Button Switches certain function keys on the remote control for DVD functions. 5. SOURCE Button* Each time the button is pressed, the audio / video source will change in the following sequence: DVD > AUX > AV1. 6. AUTO MEMORY Button (AUTO PROGRAM Button)** When the AUTO MEMORY button is pressed, all channels are searched and channels that are detected with signals of sufficient levels are automatically stored in memory. 7.
14. OK Button (ENTER) Used to implement a selected setting or menu option. 15. MENU Button Allows the user to access the DVD menu(DVD MODE). 16. REPEAT Button Allows the user to repeat a selected title, chapter, or track. 17. AUDIO Button Press to display and select the available AUDIO languages in DVD mode. Each time you press the button, the language changes. Note: The languages for audio vary from disc to disc. 18. SUBTITLE Button Press to display and select the available subtitle language in DVD mode.
26. A-B Button Allow user to repeat the playback from point A to point B. Press A-B buttonOn-Screen DisplayDVD player Once Twice 3 times Repeat ARepeat AB AB Off Mark the beginning of the section to repeat (Set point A) Mark the end of the section to repeat (Set point B) Cancel the A-B repeat function 27. ZOOM Button Press this button to enlarge the picture when playing a DVD disc.
33. VOLUME DOWN (–) or UP (+)* Press to decrease or increase the level of the picture adjustments. 34. NUMBER Buttons Allow the user to enter numbers 0 to 9 for selection of selection of CD tracks, DVD chapters and password. 35. EJECT () Button* This button is used to eject the disc. MENU ADJUSTMENT The System Menu Contains features and options that let you customize your system to change the screen mode display, OSD language and source default. 1.
OSD LANGUAGE This allows the user to select the language for the on-screen display. The user can either select English, Spanish, French or German for the OSD language. SYSTEM MENU SCREEN MODE OSD LANGUAGE SOURCE DEFAULT DVD OSD LANGUAGE ENGLISH SPANISH FRENCH GERMAN SOURCE DEFAULT DVD This allows the user to select from: DVD default on- Whenever the unit is turned on it will return to DVD mode. DVD default off- Whenever the unit is turned on it will return to the last source selected.
5. Repeat steps 3~4 to continue setting the options that reside on the same Setup Page. 6. To change to another Setup page, press t until the highlight moves back to the icon on the top part of the Setup Menu. Then, repeat steps 2~5. Exiting the Setup Menu Press the SETUP button again only. LANGUAGE SETUP Language for On-Screen Display OSD MENU: The OSD MENU setup allows you to select the language for the on-screen display.
VIDEO SETUP TV Display Language TV display Video TV type 4:3 16:9 The TV DISPLAY setup allows you to adjust screen Rating setting (aspect ratio). Misc 4:3 This displays the wide picture with black bands on the upper and lower portions of the screen. 16:9 This displays a wide picture with black bands on the upper and lower portion of the screen. The bandwidth will vary, depending on the aspect ratio of the disc.
Misc SETUP select "MISC” using pqbutton, then press ubutton to enter the Miscmenu. Select the subtitle you desire using pqbutton, then press "ENTER" to confirm the setting. Press tbutton to return. Load Factory Load Factory allows you to reset all options to factory settings. * This function will not affect the Rating control settings.
Playing MP3 Discs MP3 is a format for storing digital audio. An audio CD-quality song can be compressed into the MP3 format with very little loss of quality, while taking up much less space. CD-R discs that have been encoded in MP3 format can be played on your DVD player. The DVD player plays the songs in the order they were burned on to the disc. When playback is started the elapsed time of the track that is playing will be displayed. Selecting Folders and Songs 00:00:01 /myf/001.
Repeat: play repetitively 1/12 Repeat function has 4 options: Off, Single, Folder, All. Move cursor to Repeat function and press OK, Off/Single/Folder/All are displayed in that order. Repeat default is Off; Off Single Folder All Mp 001 Flat Mode Repeat : Off Mode Normal : 002 003 004 Music Playing 005 Turn of repeat function Repeat the song being played until STOP is pressed.
In Edit Mode, if Add to program function is used, highlight Program view function and press OK; the following selections appear: 1/12 Edit Mode Mp Browser View Edit Mode Browser View Clear Program 001 Clear Program 002 003 004 Music Playing 005 Method: When Add to program function is finished, highlight the Browser view function; the songs in the new program are displayed. To delete a selected song, highlight the selected song; a check mark appears to the left of the selected song.
To load and Play a Disc Press the Power button to turn the unit ON. Select DVD mode and insert the disc (Label towards driver) into the disc compartment. TURNING THE UNIT ON OR OFF 1. Pushing in the Screen Release button will unlock the LCD screen and it will drop down slightly. Pivot the screen downward until a comfortable viewing angle is reached. The hinge friction will hold the screen in position while the system is in use. 2.
ACCESSORIES WIRELESS HEADPHONES (OPTIONAL) The MMD11 A includes a built-in infrared transmitter for use with the supplied wireless headphones. The headphone volume is adjusted using the controls on each headset. Any number of wireless headphones may be used but they must be used within a line of sight from the transmitter, as infrared transmissions, like visible light travel only in a straight line. See the documentation accompanying your wireless headphones.
TROUBLESHOOTING PROBLEM SOLUTION IR remote inoperative Verify that the batteries in the remote are fresh. Verify that the remote sensor eye is not obstructed. Disc won't play Insert a disc with the label side facing up. Check the type of disc you put into disc tray. This DVD only plays DVDs, audio CDs and MP3s. Both the unit and the disc are coded by region. If the regional codes don’t match, the disc can’t be played. This DVD player is set to Region Number 1.
REPLACEMENT PARTS Remote Control 136-4196 SPECIFICATIONS LCD Backlighting Edge Light Tube Resolution 800 x RGB x 480 Pixels 1, 152, 000 Operation Temperature 32 ~131º F (0 ~ 55º C) Storage Temperature -4 ~ 158º F (-20 ~ 70º C) Backlit life 15,000 Hours Video Display System NTSC / PAL Video Output 1.0Vp-p @ 75 ohms Power Source 12V DC Dimension LxWxH 14.0” x 12.0” x 2.0” 356mm x 305mm x 60mm Specifications subject to change without notice.
Applies to Movies To Go Mobile Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workman ship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
