User's Manual

Studio Broadcast System
Page 5 of 26
2.2 Specifications
Overall System
Dynamic Range
>109 dB (A-weighted, typical)
Total Harmonic Distortion
<0.06% (-40dBV input level)
BP24 Specs (inherent to beltpack /
Direct connect
Self Noise @ 0dB gain
-111dBA
Self Noise @ 20dB gain
-106dBA
Sensitivity @ 0dB gain
-44dBV
Sensitivity @ 20dB gain
-23dBV
Dynamic Range
111dB (A-weighted, typical)
SNR @ 0dB gain
67dBA
SNR @ 20 dB gain
82dBA
Maximum Input Level (5% THD)
4.8dBV
Total Harmonic Distortion
<0.06% (-40dBV input level)
Operating Frequency Range
6250MHz – 6750MHz
Tx Output Power
2nW mean
Modulation
none
Emissions Designator
500MN1W
