2.3 System Components
Model
Description
BP24
Body Pack Transmitter with Talkback Function
RP32
UWB Receiver and Antenna Module
MCU3224
Main Control Interface Unit (3U)
AT899cL4 or
cL4SW
Microphone
Microphone with Inline Talkback Switch
2.4 System Block Diagram
`
MAIN CONTROL INTERFACE UNIT
(3U)
TX
1
. . .
TX
24
RX
1
RX
32
. . .
Wireless Links
(TDMA)
Cat 5 - All RX Home Run to Main
Control Unit
. . .
Mains In (Red)
Mains In (Blue)
Network Control
(Future) Ethernet
Network Audio
Dante
(Future) Ethernet
BNC-Audio
Word Clock In
Word Clock Out
MADI
75Ω co-ax
MADI
Fiber (GBIC)
Fiber Out
Audio CH 1-8
7” TOUCH SCREEN
GUI
(on-board)
FUTURE Analog Break Out
Box x8
Or AES 3 Outputs
FUTURE Analog Break Out
Box x8
Or AES 3 Outputs
(Future)
FUTURE Analog Break Out
Box x8
Or AES 3 Outputs
Dante 1
Dante 2
Audio CH 9-16
Audio CH 17-24
x24
x32
Fiber In
