 Test Mode – activates a test tone through the system so that
the user can carry out a constant-signal walkout test while
setting up and de-bugging the system. NOTE: No normal audio
operation is available when in the test tone mode, and the
mode must be exited in order for the system to operate
normally.
To enter and activate any of the TOOLS screen functions, press on the screen graphic for
the desired parameter. The display for the selected parameter will blink. Press the “SET”
button on the number pad to confirm the change.
To enter TEST MODE, press on the screen graphic at the “OFF” position under test mode.
The parameter will begin to blink. Enter the Audio-Technica phone number using the
key pad by pressing 330 686 2600 and then press “SET.” The display for TEST MODE will
now change to a green color and display “ACTIVE.” To immediately stop the TEST TONE,
press on the screen where it says “OFF.”
7. QUICK START
 Using a shielded CAT 5 cable (may be used with up to 1,000 feet of cable per
channel) terminated with a standard RJ45 connector, plug the cable into the RJ45
input jack on the rear of at least one RP32 receiver. Connect the other end of the
CAT 5 cable to the RJ45 input jack on the rear of the MCU3224 main control unit.
You may connect up to 32 RP32 receivers by connecting them into the
corresponding channel output (1-32) found on the rear of the MCU.
You do not need to turn the RP on. It receives power via the CAT 5 cable
from the MCU 3224. The RP display should immediately light and display
the channel output number to which it has been connected on the MCU.
 Apply power to the MCU3224 by connecting at least one IEC cable to AC wall
supply.
