The Σ button is used to view receivers that are connected to ANY active transmitter
rather than just a single transmitter. This mode is used to test which receivers are most
effective in a given set up, and may assist in receiver placement.
When the user selects the matrix screen, the system will first check for added receivers;
without interrupting the operation of the active receivers or the audio output. This
gives the user a way to add receivers while the system is in active operation. If the user
plugs in a receiver it will not be active until the system goes through this process.
Pressing the mode swap button switches to Transmitter measurement mode.
Mode Swap Button
Σ Mode Select
