User Manual

2000 Series Installation and Operation
10
2000 Series Frequency Channel Plan
Band D
Channel Frequency-MHz
1 656 . 125
2 659 . 375
3 660 . 000
4 662 . 125
5 665 . 125
6 669 . 750
7 671 . 500
8 677 . 000
9 678 . 125
10 678 . 500
Band E
Channel Frequency-MHz
1 795.500
2 795.825
3 797.825
4 798.675
5 800.400
6 800.975
7 803.850
8 804.400
9 804.700
10 805.875
Band F
Channel Frequency-MHz
1 863 . 100
2 863 . 500
3 864 . 100
4 864 . 900
5 854 . 900
6 855 . 275
7 855 . 900
8 856 . 175
9 858 . 200
10 861 . 750
Band G
Channel Frequency-MHz
1 722.125
2 725 . 375
3 726 . 000
4 728 . 125
5 731 . 125
6 735 . 750
7 737 . 500
8 743 . 000
9 744 . 125
10 744 . 500
Band I
Channel Frequency-MHz
1 487 . 125
2 487 . 625
3 488 . 875
4 491 . 750
5 494 . 375
6 495 . 375
7 501 . 375
8 503 . 375
9 505 . 750
10 506 . 500
Band U (A)*
Channel Frequency-MHz
1 607 . 625
2 608 . 875
3 609 . 575
4 610 . 400
5 611 . 675
6 612 . 825
7 606 . 500
8 606 . 750
9 607 . 125
10 613 . 300
* Please note that the frequency range 608-614 MHz (Plan A) is illegal to use in many countries
due to radio astronomy. Please check your local regulations.
Band U (B)
Channel Frequency-MHz
1 614 . 300
2 615 . 000
3 616 . 225
4 616 . 975
5 620 . 000
6 626 . 025
7 626 . 775
8 628 . 700
9 629 . 500
10 629 . 900
CAUTION: U.S. Public Safety/Security Restrictions
(Private Land Mobile Radio Services)
Pertains to Band I Only.
Avoid the frequencies/channels listed below in each of the following
U.S. metropolitan areas (as of November 2009). Refer to www.fcc.gov
for updates.
Land Mobile Allocation
Metropolitan Areas 2000 Series I Band
Channels
TV Channels* to Avoid in
Indicated Metropolitan Areas
Boston, MA 1, 2 14, 16
Dallas, TX 1, 2 16
Detroit, MI 1, 2 15, 16
Houston, TX 3, 4 17
Los Angeles, CA 1, 2, 10 14, 16, 20
New York, NY 1, 2 14, 15, 16
Philadelphia, PA 7, 8, 9, 10 19, 20
Pittsburgh, PA 5, 6 14, 18
San Francisco, CA 1, 2, 3, 4 16, 17
Washington, DC 3, 4, 5, 6 17, 1 8
Note: Cleveland and Chicago public safety allocations (TV Channels 14 & 15) and Miami FL public
safety allocations (TV Channel 14) are outside of the 2000 Series operating bandwidth.
* The 2000 Series operates in TV channels 16-20; Channels 14 and 15 are outside the 2000 Series
operating bandwidth.
