Manual for 7-Day Programmable Thermostat (395KB)

2. ENTRY OF BASIC DATA
You may program the thermostat while holding it in your hands or once it is mounted
on the wall.
2.1 PROGRAMMING THE TIME AND DAY
1. Set the time using the Hour and Minute buttons.
2. Set the date using the Day button.
2.2 PROGRAMMING THE COMFORT, ECONOMIC AND VACATION SETTINGS
The Comfort , Economic and Vacation settings respectively represent the
temperatures that you wish to have during the day , at night or while you are away
at work , or while you are away for an extended period . Since your
thermostat controls both heating and air-conditioning, and since the economic
settings are the opposite in both cases (reduction for heating temperature, increase
for air-conditioning), you must program the settings for heating and then for
air-conditioning.
1312
1.8 BATTERY INSTALLATION
When you first install the batteries in the TH141, the unit runs a
sequence of tests and a complete reset to zero, which last
approximately 5 seconds. The screen should display the time and
the day, as well as the current temperature as follows:
It is normal for the displayed temperature to be higher than the
room temperature if your are holding the TH141 in your hands, It
will return to normal about one hour after installation on the wall.
Mount the thermostat on the wall plate and screw it in place.
Even if the thermostat indicates that the batteries are good, it is
recommended to replace them once a year, at the beginning of the cold
season.
1514
1. To program your heating settings
a) Set your thermostat to the heating mode using the Heat/Cool button.
b) To program the Comfort temperature, select the desired degree using the
buttons and press the button until the icon is displayed
(app. 3 seconds).
c) To program the Economic temperature, select the desired degree using the
buttons and press the button until the the icon is displayed
(app. 3 seconds).
d) To program the Vacation temperature, select the desired degree using the
buttons and press on the button until the icon is displayed
(app. 3 seconds). This setting is used by the telephone remote control.
e) Press the Manual/Auto button to exit this function and return to the
normal operating mode.
2.3 PROGRAM THE AIR-CONDITIONING SETTINGS
Set your thermostat to the air-conditioning mode using the Heat/Cool button
and repeat operations b) to e).
3. OPERATING MODES
The TH141 offers two operating modes.
3.1 MANUAL ()
This mode allows you to maintain a constant temperature in the house.
1. To activate this mode, press the Manual/Auto button to display the icon.
2. Set the desired temperature using the buttons or select the pre-programmed
, or settings.
3.2 AUTOMATIC ()
This mode executes your own programming. To activate this mode, press the
Manual/Auto button to display the icon. The or icon indicates that the
program setting is active.
3.2.1 SCHEDULE PROGRAMMING
The TH141 allows 4 setting changes for each day of the week. There are no pre-set
programs. The programs are tailored to perfectly adapt to your life style.
The principle is very simple. For each day, enter the time at which you wake up (P1),
the time you leave for work (P2), the time you arrive back home (P3) and the time you
go to bed (P4).
