ATTO Technology, Inc. Installation and Operation Manual Celerity FC host adapters Celerity FC-44ES 4-Gb FC quad channel host adapter Celerity FC-42ES 4-Gb FC dual channel host adapter Celerity FC-41ES 4-Gb FC single channel host adapter Celerity FC-42XS 4-Gb FC dual channel host adapter Celerity FC-41XS 4-Gb FC single channel host adapter Celerity FC-21PS 2-Gb FC single channel host adapter Celerity FC-24XL 2-Gb FC quad channel host adapter with IOPC architecture © 2006 ATTO Technology, Inc.
Contents 1 ATTO provides Fibre Channel solutions ..........................................
2 Fibre Channel is a key technology for storage ................................9 Glossary 3 Hardware installation .........................................................................11 System requirements Fibre Channel address Installation Bracket details Adapter board details 4 Configuring and updating drivers .....................................................
1 ATTO provides Fibre Channel solutions The ATTO Celerity Fibre Channel family of storage products provides connectivity, intelligence and scalability. Celerity FC host adapters simplify advanced storage networking needs such as switching, backup and data management. Specifically designed to enhance the functionality of third party fabric hardware and software, Celerity FC products are the industry-leading platform for storage connectivity.
Celerity FC-42ES Adapter The Celerity FC-42ES is a dual-channel host adapter, providing port density for Enterprise server and workstation applications. With 4-Gb FC speeds of up to 800 MB/second per channel, the FC-42ES supports the most demanding application requirements. Additionally the FC-42ES takes advantage of the latest in host interconnect technology, PCI Express, a serial, high-speed connection that supports aggregate throughput up to 2 GB/second (x8 PCIe).
Celerity FC-41ES Adapter The Celerity FC-41ES is a single-channel host adapter providing support for the most demanding application requirements. With 4-Gb FC speeds of up to 800 MB/sec. per channel, the FC-41ES is a cost effective connectivity solution for environments requiring maximum throughput. The FC-41ES also takes advantage of the latest in host interconnect technology: PCI Express, a serial, high-speed connection that supports aggregate throughput up to 1 GB/sec. (x4 PCIe).
Celerity FC-42XS Adapter The dual-channel Celerity FC-42XS host adapter provides the highest available throughput for Fibre Channel applications while protecting technology investments via backward compatibility with existing infrastructure. With speeds of up to 800 MB/sec. per channel, the FC42XS is capable of supporting the most intensive data applications.
Celerity FC-41XS Adapter The single-channel Celerity FC-41XS provides speeds of up to 800 MB/sec. using full 4-Gigabit Fibre Channel performance while being fully backwardcompatible with existing 2-GB and 1-Gb Fibre Channel infrastructure, protecting existing technology investments. It is capable of supporting the most dataintense applications. Hardware specifications • • • • • • • • • One Fibre Channel port 4-Gigabit data transfer rates per channel 800 MB/sec.
Celerity FC-21PS Adapter The Celerity FC-21PS Fibre Channel host adapter provides a single 2-Gb Fibre Channel connection from host devices to the Storage Area Network (SAN) fabric. The FC-21PS supports the leading operating systems, providing a single solution for all connectivity needs.
Celerity FC-24XL Adapter The Celerity FC-24XL is a Fibre Channel advanced host adapter with four independent channels of 2-Gb connectivity and advanced functions and embedded processing and buffering capabilities to enable data stream manipulation, direct port-to-port transfers, offload processing, video handling and a myriad of other capabilities.
Celerity Selection Guide Celerity FC host adapters Product FC-44ES Features ............. FC-42ES FC-41ES FC-42XS FC-41XS FC-24XL FC-21PS 4 2 1 2 1 4 1 4-Gb 4-Gb 4 GB 4-Gb 4-Gb 2-Gb 2-Gb Maximum Transfer Rate (half duplex) 1.
2 Fibre Channel is a key technology for storage Fibre Channel is a serial communications technology designed to transfer large amounts of data among a variety of hardware systems over long distances. It is a key technology for applications that require shared, high bandwidth access to storage. Fibre Channel provides a logical, point-to-point, serial channel for the transfer of data between a buffer at a source device and a buffer at a destination device.
Term Definition fabric a Fibre Channel switch or two or more Fibre Channel switches interconnected to physically transmit data between any two N_Ports on the switch or switches FC Fibre Channel F_port a port in the Fibre Channel fabric where a N_port may attach FL_port a port in the Fibre Channel fabric where a NL_port may attach in an arbitrated loop frame an indivisible unit for transfer of information in Fibre Channel frame header the first field in the frame containing the address and other
3 Hardware installation You need a basic understanding of Fibre Channel before installing the Celerity FC host adapter. Please refer to Fibre Channel is a key technology for storage on page 9 for a list of related web sites. WWN 0 WWN 1: WWN 2 WWN 3 CAUTION Back up your system data before changing or installing any hardware. System requirements The Celerity FC host adapter package contains the host adapter, the ATTO Utilities CD and a warranty and registration card.
Bracket details Exhibit 3-1 FC-44ES Adapter Exhibit 3-3 FC-41ES Adapter Link LEDS If Link LED is lit, the storage adapter is online Speed LEDs indicate 4Gb SFP LC optical connectors Speed LED indicate 4Gb Link LED If Link LED is lit, the storage adapter is online SFP LC optical connector Exhibit 3-4 Exhibit 3-2 Speed LEDs indicate 4Gb FC-42XS Adapter FC-42ES Adapter Link LEDS If Link LED is lit, the storage adapter is online SFP LC optical connectors 12
Exhibit 3-5 FC-41XS Adapter Exhibit 3-7 FC-24XL Advanced Adapter If LED lit, indicates the channel is using 2-Gb FC If LED lit, the storage adapter is online If LED lit, adapter is online SFP LC optical connectors SFP LC optical connector FC24XL Exhibit 3-6 FC-21PS Adapter If LED lit, indicates the channel is using 2-Gb FC If LED lit, the storage adapter is online SFF duplex LC optical connector 13 ATTO Technology Inc.
Adapter board details Exhibit 3-8 FC-44ES FC controller SFP LC optical connectors PCI Express connector Exhibit 3-9 FC-42ES Non-RoHS FC c o n tro lle r S F P L C o p tic a l c o n n e c to rs P C I E x p re s s c o n n e c to r 14
Exhibit 3-10 FC-42ES RoHS F C co n tro lle r S F P L C o p tica l co n n e cto rs P C I E xp re ss co n n e cto r Exhibit 3-11 FC-41ES FC controller SFP LC optical connector PCI Express connector 15 ATTO Technology Inc.
Exhibit 3-12 FC-42XS F C c o n tro lle r SFP LC o p tic a l c o n n e c tors P C I-X c o n n e c to r Exhibit 3-13 FC-41XS FC controller SFP LC optical connector PCI-X connector Exhibit 3-14 FC-21PS SFF duplex LC optical connector FC controller PCI connector 16
Exhibit 3-15 FC-24XL Intel 80331 XScale pluggable SFP LC optical connectors FC controllers PCI-X connector 17 ATTO Technology Inc.
18
4 Configuring and updating drivers Celerity FC host adapters require a current device driver and hardware flash for proper operation. Your adapter was properly flashed before shipment, but the flash memory may need to be updated as new versions become available or if the factory-installed version becomes corrupt. This chapter deals with installing and updating device drivers. Refer to Updating hardware flash on page 22 for information on updating hardware flash. Visit the ATTO web site, www.attotech.
Adding a Celerity FC adapter to an existing Windows installation Note Complete this installation procedure before attaching any devices to the adapter. 1 Complete the steps in Upgrading your existing Celerity FC driver on page 19 to pre-install the driver. 2 Shutdown Windows when Setup prompts you to do so. 3 Install your new Celerity FC adapter into an available PCI expansion slot. 4 Restart Windows.
Create a Celerity FC installation floppy disk from the Celerity FC Installation CD 1 Create a floppy disk from a Celerity FC driver download from the ATTO Technology website Note You must have a floppy disk with the Celerity FC driver software to install a fresh copy of the Windows OS onto a disk attached to a Celerity FC adapter. 1 Download the latest driver software from the ATTO web site, www.attotech.com. 2 Insert the Installation CD into a CD-ROM. The installation starts automatically start.
5 Updating hardware flash Your Celerity FC host adapter was properly flashed before shipment, but the flash memory may need to be updated as new versions become available or if the factory-installed version becomes corrupt. Visit the ATTO website, www.attotech.com, to download the latest drivers and flash bundle. the self-extracting executable and select a folder in which to place the expanded software package.
6 Troubleshooting This chapter contains solutions for the most common problems you might encounter. If you need additional assistance, please refer to the ATTO Technology web site (www.attotech.com) or contact an ATTO Technology authorized representative. General suggestions • Check each cable connection on every device. • Verify all cables are in proper working condition. Loose or broken cables are often the cause of errors or problems.
• a. Remove power from the PC. If these do not solve the problem, re-flash the host adapter and re-install the Windows 2000/XP/Server 2003 driver. See Configuring and updating drivers on page 19. If the devices connected to the Celerity FC host adapter are not accessible 1 Right-click My Computer. 2 Select Properties. 3 Select the Hardware tab. 4 Select Device Manager.
Appendix A Standards and compliances The equipment described in this manual generates and uses radio frequency energy. The Technical Specification sheet for a particular Celerity FC host adapter list certifications for that model. FCC standards: radio and television interference WARNING This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Usage restrictions The use of optical instruments with this product will increase eye hazard. The multimode transceiver is a Class 1 laser product complying with IEC 825-1 and FDA-21 CFR 1040.11. To meet laser safety requirements, the transceiver shall be operated within the maximum ratings. The laser is non-OFC compliant as it is a Class 1 device. The optical ports of the modules must be terminated with an optical connector or with a dust plug.
Appendix B Accessories The following Fibre Channel accessories are available through ATTO Technology and authorized resellers. Contact an ATTO Technology authorized sales representative to order. Optical Cables CBL-FCFI-05x CBL-LCSC-003 CBL-LCSC-010 5 m. cable– Duplex 50 Micron Multi-mode FC/Optical 3 m. 50/125 optical cable (LC to SC) 10 m. 50/125 optical cable (LC to SC) A variety of iSCSI, Fibre Channel and SCSI products are also available from ATTO Technology.
Appendix C SCSI adapter selection guide Ultra 320 Product Features UL5D UL4D UL4S 640 640 320 Low Voltage Differential 9 9 9 Single-ended SCSI 9 9 9 Number of SCSI channels 2 2 1 Number of SCSI IDs supported 30 30 30 Cable distances (m) 12.5 12.5 12.5 Large file transfers 9 9 9 32-bit PCI compatible 9 9 64-bit PCI compatible 9 9 33 MHz PCI 9 9 66 MHz PCI 9 9 133 MHz PCI-X 9 9 Maximum Transfer Rate (MB/sec.
Appendix D Contact ATTO Technology, Inc. Customer service, sales information and technical support are available by phone Monday through Friday, Eastern Standard Time 8:00 a.m. to 8:00 p.m., or by e-mail and web site 24-hours a day. ATTO Technology, Inc. 155 CrossPoint Parkway Amherst, New York 14068 (716) 691-1999 • voice (716) 691-9353 • fax http://www.attotech.com ATTO Technology can also be reached via e-mail at the following addresses: Sales Support: Technical Support: sls@attotech.
