ERGO BACKPACK VACUUM OWNER’S MANUAL Model: VACBP1 120V 12A, 1400W ETL US Canada Atrix 1350 Larc Industrial Blvd. Burnsville, MN 55337 www.atrix.com sales@atrix.com Telephone: 952.894.6154 Toll Free Telephone: 800.222.6154 Fax: 952.894.
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING APPLIANCE WARNING: TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR INJURY: Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. 2. Electrical shock may occur if used outdoors or on wet surfaces. 3. Do not allow to be used as a toy. Close attention is necessary when used by or near children. 4.
GETTING TO KNOW YOUR ERGO BACKPACK VACUUM 3
15. Telescopic Tube Button 1. Main Unit 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. Exhaust Grill On/Off Power Switch Canister Lid Tabs Waist Band Shoulder Straps Back Board Panel Carry Handle Hose Inlet Canister Lid Flexible Hose Flexible Hose handle Variable Suction Control Telescopic Tube 16. 17. 18. 19. Waist Band Back Support Panel Waist Band Oval Dusting Brush Crevice Tool 20. 21. 22. 23. 24. 25.
6 Ensure that the shake-out bag is in place. (Fig. 4) 8 The canister lid can be replaced on the unit with the hose opening on the right or left, as per your preference. (Fig. 5) (Fig. 4) 7 Flip the HEPA bag holder over, pressing the tab on the bag holder until it clicks, then replace the canister lid. (Fig. 5) Attaching the Flexible Hose to the Vacuum Attaching the Telescopic Tube to the Flexible Hose Handle The flexible hose should be connected to the vacuum before strapping the unit to your back.
Manual Suction Control Your vacuum cleaner includes a manual variable suction control on the flexible hose handle. The suction power can be adjusted by moving the suction regulator to the desired position between open and closed. (Fig. 10) Open gives you less suction, closed maximum suction. For example, less suction is required on upholstery and draperies compared to thick carpets, which require maximum suction.
Blower Attachments The blower attachments can be used with the vacuum to pick up very fine dirt particles in tight crevices or spots, or to inflate inflatable items or air mattresses. The blower attachments have air bleed holes. These air bleed holes help relieve some air pressure so that the attachment does not blow off. However, should an increase in air pressure be desired, simply cover one or more of the air bleed holes.
Warning: To reduce the risk of electric shock, the power cord must be disconnected before removing the dust bag, shake-out bag, changing the filters or performing maintenance or trouble-shooting checks. 4 Turn the unit on by pressing the switch located near the base of the unit to turn the vacuum cleaner on. (Fig. 17) (Fig. 19) 4 Replace the HEPA dust bag with a new bag. Do not reuse the same bag. 5 The cardboard face of the new bag should rest securely in the dust bag cover guides. (Fig. 20) (Fig.
Cleaning the Shake-Out Bag: 1 Remove the shake-out bag, shake vigorously outdoors or over your trash bin until there is no more dust. 2 The shake-out bag is hand washable in lukewarm water. 3 Allow to air dry for 24 hours. The shake-out bag should be replaced when needed. Never replace into the vacuum if still wet 4 Replace clean shake-out bag in unit, and replace the canister lid onto the vacuum. Cleaning the HEPA Pre-Motor Filter 1 Remove the shake-out bag from the canister.
How to properly use the cord relief: Warning: To reduce the risk of electric shock, the power cord must be disconnected before removing the dust bag, shake-out bag, changing the filters or performing maintenance or trouble-shooting checks.
______________________11______________________ Ergo Backpack Schematic Product SKU: VACBP1 © 2018 Atrix. All Rights Reserved.
______________________12______________________ Atrix ERGO Backpack Vacuum WARRANTY INFORMATION Warranty/Service Information: For warranty service information, please contact Atrix or your local Atrix distributor. Atrix ERGO Backpack Vacuum Limited Warranty: To the original user purchasing the Atrix ERGO Backpack Vacuum, Atrix warrants that the vacuum will be free of defects in material and manufacture for a period of one (1) year from the date of purchase.
