Atop Industrial Serial Device Server
SE5408A/SE5416A Series
User Manual V 1.0
22
2.Local port
Display/Change Local
listening port
3.Max
connect
Display/Change
maximum client
connection (1~4)
4.IP Filter
1.Disable
Display/Change IP Filter
function and the IP
address
2.Enable
5. Apply to all
1.No
2.Yes
Apply Link mode Settings
to all serial ports
2.TCP client
1.Dest IP 1
Display/Change
Destination IP 1
2.Dest port 1
Display/Change
Destination port 1
3.Destination
2
1.Disable
Disable destination 2
2.Enable
Display/Change
Destination IP 2 and
Destination port 2
4. Apply to all
1.No
2.Yes
Apply Link mode Settings
to all serial ports
3.UDP
1.Local port
Display/Change Local
listening port
2.Dest IP1
Display/Change
Destination IP 1
3.Dest port 1
Display/Change
Destination Port 1
4.Destination
[2-8]
1.Disable
Disable Destination [2-8]
2.Enable
Display/Change
Destination IP [2-8] and
Destination port [2-8]
