Atop Industrial Serial Device Server
SE5408A/SE5416A Series
User Manual V 1.0
17
3.6 Factory Default Settings
Upon arrival, the device will be set as follows:
Parameters
Default Values
LAN 1
IP Address
10.0.50.100
Gateway
10.0.0.254
Subnet Mask
255.255.0.0
LAN 2
IP Address
192.168.1.1
Gateway
192.168.1.254
Subnet Mask
255.255.255.0
User Name
admin
Password
null (leave it blank)
COM
RS-232 (RS-422 if RS-232 is unavailable), 9600, None, 8,1,No Flow
Control
COM Link Mode
Mode: RAW, Type: TCP Server, Listen port 4660, Filter=0.0.0.0
